Description
1
Mounting screw hole/mounting foot
2
Removable Terminal Block (RTB)
3
RTB hold down screws
4
Module interconnect latch
You can choose to wire the expansion I/O module before installing it next to the
controller or wire it once the module is secured in place.
Place the module next to the controller against the panel where you are mounting
it. Make sure the controller and module are spaced properly.
NOTE
2.3.4 Insert Module Next to the Controller
Follow the instructions to insert and secure the expansion I/O module to the
controller:
NOTE
NOTE
•
This equipment is considered Group 1, Class A industrial
equipment according to IEC/CISPR 11. Without appropriate
precautions, there may be difficulties with electromagnetic
compatibility in residential and other environments due to
conducted and radiated disturbance.
•
Be careful when stripping wires. Wire fragments that fall into the
controller could cause damage. Once wiring is complete, make
sure the controller is free of all metal fragments before removing
the protective debris strip.
Do not wire more than 2 conductors on any single terminal.
•
•
If you insert or remove the expansion I/O module while power is
on, an electrical arc can occur. This could cause an explosion in
hazardous location installations. Be sure that power is removed or
the area is nonhazardous before proceeding.
The module expansion may only be mounted horizontally.
For environments with greater vibration and shock concerns, use the panel
mounting method, instead of DIN rail mounting.
Chapter 2: Installation and Wiring
Description
5
DIN rail mounting latch
6
I/O Status LEDs
7
Bus Connector (2, Right and Left)
User's Manual Pub. 0300309-01 Rev. B
2-5
