Compliance to
European
Union Directives
WARNING
Chapter 2
Installation and Wiring
This chapter will cover:

Compliance to European union directives

Power requirements
General considerations
Mounting
This product is approved for installation within the European Union and EEA
regions. It has been designed and tested to meet the following directives.

2.1.1 EMC Directive

This product is tested to meet Council Directive 2014/30/EU Electromagnetic
Compatibility (EMC) and the following standards, in whole or in part,
documented in a technical construction file:
EN 61000-6-4 Electromagnetic compatibility (EMC)–Part 6-4: Generic
standards–Emission standard for industrial environments.
EN 61000-6-2 Electromagnetic compatibility (EMC)–Part 6-2: Generic
standards–Immunity for industrial environments.
UKCA Electromagnetic Compatibility Regulations 2016
BS EN 61131-2, BS EN 61000-6-4, BS EN 61000-6-2.
This product is intended for use in an industrial environment.
The backplane power and each field power of the device shall only be
supplied by Isolated Secondary Limited Energy Low Voltage sources.
The module receives power through the bus interface from the +5 VDC (4.75 V
to 5.4 V)/±24 VDC (19.9 V to 26.4 V) system power supply, and a 24 VDC field
power supply. Both must be present for the module to operate.
Backplane current ratings: + 5 V rail is 70 mA maximum at 5 VDC; +24 V rail is
55 mA maximum at 24 VDC. Power rating for OB32 is 5.5 Watts maximum (at
full load); for OV32 is 4 Watts max. (at full load):
5 VDC
70 mA
24 VDC
55 mA
User's Manual Pub. 0300309-01 Rev. B
