Configuring the Micro800 Expansion I/O 2085-OX32-SC Using CCW
Chapter 3:
NOTE
2085-OX32-SC
Tab on CCW
NOTE
You can directly control channel output through the CCW output variable
or your own ladder program. No default configuration is required. The
modules do NOT use the third-party, MCC tool for configuration.
5. To view default configuration information, click the Default
Configuration tab:
The modules do not use the third-party, MCC tool for configuration.
Before you start, if needed, install the latest version of Rockwell Automation's
Connected Components Workbench (CCW) Standard Edition.
Using the Module Profile Tool to import the 2085-OX32-SC AOP into
CCW software is necessary only if you are using a CCW version earlier
than 11.00.00. For information on manually importing an AOP file, see
Appendix A. For Version 11.00.00 and later, the modules are already
available as a selection from the CCW Expansion Modules drop-down
menu:
User's Manual Pub. 0300309-01 Rev. B
3-5
