STO, RCL and IDENTIFY buttons, a RESET TO XGA/1080P button (to hardware-reset
the output resolution) and a PANEL LOCK button.
•
Built-in video Proc-Amp – color, hue, sharpness, contrast, and brightness are set
individually for each input.
•
Firmware Upgrade – Ethernet-based, via a user-friendly software upgrade tool.
•
Advanced EDID management per input.
•
Includes non-volatile memory that retains the last settings, after switching the power off
and then on again.
Flexible Connectivity
•
4 HDMI Inputs and 4 Scaled HDMI Outputs.
•
4 balanced audio outputs with independent volume settings per output, embedded audio
on the HDMI inputs and outputs.

Typical Applications

VSM-4x4X is ideal for the following typical applications:
•
Presentation and multimedia.
•
Projection systems in conference rooms, boardrooms, auditoriums, hotels and churches,
production studios, rental and staging.
•
Video wall: large signage applications in public places.
•
Any application where high quality conversion and switching of multiple and different
video signals to graphical data signals is required for display or projection purposes.
Controlling your VSM-4x4X
Control your VSM-4x4X
•
Via the Ethernet using built-in user-friendly Web pages.
•
By RS-232 serial commands transmitted by a touch screen system, PC, or other serial
controller.
•
Remotely, from the infrared remote control transmitter.
VSM-4x4X – Introduction
directly via the front panel push buttons (with on-screen menus, or:
