The following is a general overview of this function menu, and the detailed pa-
rameters of the waveform corresponding to each protocol/standard can be
found in the corresponding chapter.
Road-
Vehicles
Recall the Vehicle Waveform
Select any of the above five kinds of vehicle waveforms, after completing the
waveform parameter setting (see the subsequent introduction for each parame-
ter), the system will automatically enter the waveform recalling mode and wait
for the triggering operation. At this time, the VFD screen is displayed as the
main interface of the system, and the corresponding waveform name is dis-
played in the lower right corner.
Run the Vehicle Waveform
After turning on [On/Off], the output of the vehicle waveform is triggered accord-
ing to the selected trigger method.
If there is a waveform parameter related to setting the voltage val-
ue, when the upper limit of the voltage setting defined in the reg-
ulation exceeds the rated voltage of the instrument, the rated
voltage of the instrument is set as the upper limit. Otherwise, the
output waveform may be distorted.
Vehicle waveform function menu
DIN40839
ISO16750-2
ISO21848
SAEJ1113-11
LV123
LV124
Copyright © Itech Electronic Co., Ltd.
Power Supply Function
Evaluation of automotive starting
waveform
Simulate the waveform to verify the
anti-interference performance of the au-
tomotive electronics' products.
42V Road vehicles — Electrical and
electronic equipment for a supply volt-
age of 42 V — Electrical loads
SAEJ1113-11 Waveform protocol
LV123 Waveform protocol
LV124 Waveform protocol
