ITech IT-M3900B Series User Manual page 202

Taking the CV program setting as an example, the user needs to convert the M
and b values based on the formula below. And set these two values respectively
through the front panel keys (or the SCPI remote command).
Formula parameter descriptions:
Name
V
in1
V
in2
V
out1
V
out2
Analog Control
The pin connection method and instrument operation method in four basic
modes of the load are the same. The voltage control in CV mode is taken as an
example below to describe the connection and usage.
1. Refer to the figure below to complete the pin connection.
The setting principles of calculation parameters in other modes are the same.
Copyright © Itech Electronic Co., Ltd.
Description
Indicates the start voltage input to pin 8. The
setting range is from –10 to 10.
Indicates the end voltage input to pin 8. The
setting range is from –10 to 10, and V
V .
in1
The starting value of the input voltage in CV
mode.
The end value of the input voltage in CV
mode, and V > V
out2 out1
Basic Operation
>
in2
.
190
