1. Press the composite keys [Shift]+[V-set] (Config) on the front panel to enter
2. Use knob to select Von and press [Enter].
3. Use knob or left/right key to select the desired Von mode.
4. Use number keys or knob to set Level and press [Enter].

5.2 Advanced Feature

5.2.1 LIST Function

The IT-M3900B series power system supports a total of 10 List files (List01 to
List10), each of which can be set up to 200 steps. You need to edit the voltage/
current value, slope and time width of each step, or you can set repeat times (1
to 65535) for each List file. After the file is edited completely, you can trigger the
selected List file to run according to the selected trigger mode.
。The descriptions of list function menu are listed in the table below.
LIST
the configuration menu.
Latch mode
Living mode
List menu
Run
Indicates to enter the List run mode, waiting for the trigger to
run the currently selected List file.
Open
Select the List file to open.
USB
Internal
Export Export the internal List file of the instrument to an external
USB flash drive.
File
Name
Copyright © Itech Electronic Co., Ltd.
Open the List file in the external USB flash disk.
Load
Import the List file from the exter-
nal USB flash disk into the
instrument.
Not-Load
Cancel the import operation.
Open the List file stored inside the instrument.
Recall Inner
Set the name of the recalled List
List File
file.
The name of the exported list file. The default suf-
fix is .csv, and the file name can only be a string
of numbers.
Load Function
