INTERVAL
1000 hours or every 6 Change the hydraulic oil. Drain oil from plug
months. (item 3). Clean the oil strainer. Through fi ll plug
(item 5), add 20 gallons (75 liters)
oil level at item 2.
Check control lever.
* NOTE: Clean the oil strainer screen and change the oil fi lter after the fi rst 250 hours on new and rebuilt winches.
† Amount of oil may vary slightly with tractor.
CHECK & ADD OIL
HERE
DIPSTICK
O-RING
HYSTER-BUILT DROPBOX
PROCEDURE OR QUANTITY
Figure 15 - Maintenance Schedule
Figure 15-1 - Oil Checking/Adding Points
SPECIFICATION
See Figure 3 – Recommended Oil List.
†
. Check the
See "Control Lever Detent Force
Adjustment".
FITTING
CHECK OIL HERE
ALLIED-BUILT DROPBOX
Maintenance
FITTING
ADD OIL HERE
