Serial Number Codes

The nameplate with the serial number code is found on
the left front corner of the winch case. A serial number
indicates the following information:
Manufactured By
A = Allied Systems Company
(No "A" = Hyster Company)
Winch Model
W8L = Standard Product
K8L = Special Design (Contact Factory)
Type Drive
P = Power Controls
E = Electronic Controls
X = Direct Drive (Gear Drive)
Gear Ratio
Code = Forward Ratio/Reverse Ratio
1 = 49.8:1/19.9:1
2 = 71.6:1/28.6:1 (95.4/38.1 - K50)
3 = 94.0:1/37.6:1 (125/50 - K50)
4 = 84.0:1/33.6:1 (Non-Current)
5 = 90.1:1/36.0:1 (Non-Current)
6 = 68.8:1/27.5:1 (49.8/19.9 Winch x 1.38 Gearbox)
7 = 47.1:1/31.1:1
8 = 125:1/190:1 (94/143 Winch x 1.33 Gearbox)
9 = 94:1/102:1
10 = 125:1/136:1 (94/102 Winch x 1.33 Gearbox)
11 = 85.4:1/34.1:1 (49.8/19.9 Winch x 1.71 Gearbox)
A W8L P 3 N 1555 H51
F = Freespool (Non-current. See Appendix A for details)
Notes: 1. In Addition to the serial number plate,
the serial number is stamped on to the
left hand side of the frame
2.
Circled numbers in Figure 7 indicate
possible gear ratios.
General
Vehicle Code
See Figure 7
Sequence Number
Internal Option
N = Non-Freespool
V = Underwind Non-Freespool
