W8L Winch Description - Allied Systems W8L Operating Manual

W8L Winch Description

14
3
4, 9
2
1. Drum
2. Access Cover for Filter
3. Access Cover to Hydraulic Valve
4. Access Cover to Hydraulic System
5. Plug to Check Oil Level
6. Plug to Drain Oil
1
15
12
7. Tie Rod
8. Fill Plug
9. Cover for Oil Brake
10. Intermediate Shaft Bearing Retainer
11. Drum Shaft Bearing Retainer
12. Drawbar
Figure 5 - W8L Winch
6
13. Breather
14. Nameplate
15. Drawbar Pin
16. Clutch Shaft Retainer
17. Brake Shaft Retainer
General
