Turntable - Manitowoc Grove RT880E Service And Maintenance Manual

RT880E SERVICE MANUAL
Lube Point
Item
Description

Turntable

Turntable Gear
30
Box
Turntable Gear
31
and Drive Pinion

Turntable

32
Bearing
NOTE: Rotate the turntable 90° and apply grease to fittings. Continue rotating 90° and grease the fittings until the whole
bearing is greased.
Turntable Lock
33
Pin
Grove
Figure Approved
No. Lubricant
GL-5
Extended
Figure 9-5 Service Interval
Gear Lubricant
6829012964
EP-OGL
Open Gear
Figure 9-5
Lubricant
6829102971
EP-MPG
Extreme
Pressure
Figure 9-5
Multipurpose
Grease
6829003477
EP-OGL
Not Open Gear
Shown Lubricant
6829102971
Published 11-10-2014, Control # 524-00
Lube
Lube Interval
Capacity
• Check and fill every
50 hours
5.7 qt
• Drain and fill after
5.4 l
first 250 hours and
every 500 hours or
12 months thereafter.
Coat all
500 hours or 6 months
teeth
Until
grease
extrudes
the whole 500 hours or 6 months
circumfer-
ence of the
bearing
Coat pin 500 hours or 6 months
LUBRICATION
Application
Use Dipstick
Spray on
2 grease fittings at
the front of the
turntable.
Spray on
9
9-17
