Boom; Boom (Continued) - Manitowoc Grove RT880E Service And Maintenance Manual

RT880E SERVICE MANUAL
Lube Point
Item
Description

Boom

Hook Block
70
Swivel Bearing
Hook Block
71
Sheaves
72 Headache Ball
Telescope
73 Cylinder Wear
Pads
NOTE:
• For service of the boom, that is to be extended greater than 120 ft, the counterweight must be installed on the turntable and the
outriggers must be fully extended. Superstructure could be in any slew position. No rigging, no hookblock nor overhaul ball may
be installed on the nose of the boom. Extend boom to desired length at a boom angle of 20°. Lower boom until RCL limits the
boom lower function. Override RCL per RCL operators manual and lower boom to desired angle.
• Should boom chatter or rubbing noises in the boom occur, it will be necessary to lubricate the telescope cylinder wear
pads. By adding an extension adapter to a grease gun the wear pads and wear areas can be reached through the
lubrication access holes in the side of the boom and through the access hole in the boom nose between the sheaves.
• Lubricate more frequently than interval indicated in table if environmental conditions and/or operating conditions
necessitate.
Internal Side and
Bottom Wear
74
Pads (Inner
Sections)
Boom Section
75 Upper Wear
Pads
• For service of the boom, that is to be extended greater than 120 ft, the counterweight must be installed on the turntable and the
outriggers must be fully extended. Superstructure could be in any slew position. No rigging, no hookblock nor overhaul ball may
be installed on the nose of the boom. Extend boom to desired length at a boom angle of 20°. Lower boom until RCL limits the
boom lower function. Override RCL per RCL operators manual and lower boom to desired angle.
• Lubricate more frequently than interval indicated in table if environmental conditions and/or operating conditions
necessitate.
Grove
Figure Approved
No. Lubricant
EP-MPG
Extreme Pressure
Figure 9-8
Multipurpose
Grease
6829003477
EP-MPG
Extreme Pressure
Figure 9-8
Multipurpose
Grease
6829003477
EP-MPG
Extreme
Pressure
Figure 9-8
Multipurpose
Grease
6829003477
EP-MPG
Extreme Pressure
Figure 9-8
Multipurpose
Grease
6829003477
EP-MPG
Extreme Pressure
Figure 9-8
Multipurpose
Grease
A6-829-003477
EP-MPG
Extreme Pressure
Figure 9-8
Multipurpose
Grease
A6-829-003477
Published 11-10-2014, Control # 524-00
Lube
Lube Interval
Capacity
Until
grease 250 hours or 3 months
extrudes
Until
grease 250 hours or 3 months
extrudes
Until
grease 250 hours or 3 months
extrudes
Thoroughly
Every boom teardown
coat
Thoroughly
coat all
areas the 250 hours or 3 months
wear pad
moves on
Until
grease 50 hours or 1 week
extrudes
LUBRICATION
Application
1 grease fitting
1 grease fitting per
sheave (5 fittings
total)
1 grease fitting
5 places by brush
14 places by brush;
with boom in
extended position
through access
holes in inner-mid
and outer-mid
sections
8 grease fittings;
with boom in
extended position
through access
holes
9
9-23
