HYDRAULIC SYSTEM
Item
1 Pump Port
2 Tank Port
3 RET Port
4 P STAB Port
5 T STAB Port
6 Left Rear Extension Cylinder Port
7 Left Rear jack Cylinder Port
8 Right Rear jack Cylinder Port
9 Right Rear Extension Cylinder Port
10 Right Front Extension Cylinder Port
11 Right Front jack Cylinder Port
12 Left Front jack Cylinder Port
13 Left Front Extension Cylinder Port
14 Turret Port
15 Drain Port
16 Gauge Port 1
17 Gauge Port 2
18 Gauge Port 3
2-62
Description
Published 11-10-2014, Control # 524-00
RT880E SERVICE MANUAL
Item
19 Pressure Reducing Valve PR2
20 Pressure Reducing Valve PR1
21 Solenoid Valve SV12
22 Solenoid Valve SV11
23 Solenoid Valve SV10
24 Solenoid Valve SV9
25 Pilot Operated Check Valve POCV
26 Thermal Relief Valve RV
27 Solenoid Valve SV1 - Left Front Extension
28 Solenoid Valve SV2 - Left Front jack cylinder
29 Solenoid Valve SV3 - Right Front jack cylinder
30 Solenoid Valve SV4 - Right Front Extension
31 Solenoid Valve SV5 - Left Rear Extension
32 Solenoid Valve SV6 - Left Rear jack cylinder
33 Solenoid Valve SV7 - Right Rear jack cylinder
34 Solenoid Valve SV8 - Right Rear Extension
Description
