Manitowoc Grove RT880E Service And Maintenance Manual page 174

BOOM
Item
1 Base Section
2 Inner Mid Section
3 Outer Mid Section
4 Nose To Fly Section
5 Retract Cables
6 Cable Retainer Pin
7 Sheave Assembly
8 Anti-Two Block Plate
9 Spacer
10 Capscrew
11 Shim
12 Hex Nut
13 Lock Collar
14 Hook
15 Chain
16 Cotter Pin
17 Hitch Pin Clip
18 Shaft
19 Spacer
20 Locknut
21 Washers
22 Shim
23 Spacer
24 Pin
25 Capscrew
26 Washer
27 Keeper Plate
28 Keeper Plate
4-6
Description
Published 11-10-2014, Control # 524-00
RT880E SERVICE MANUAL
Item
29 Shim
30 Lower Wear Pad
31 Front Upper Pad
32 Top Front Pad Support
33 Capscrew
34 Flatwasher
35 Capscrew
36 Cable Pad
37 Cable Pad
38 Capscrew
39 Flatwasher
40 Top Front Adjusting Block
41 Hex Nut
42 Socket Setscrew
43 Capscrew
44 Nut
45 Mounting Angle
46 Capscrew
47 Washers
48 Capscrews
49 Flatwasher
50 Stop Block Shim
51 Stop Block Plate
52 Washer
53 Nut
54 Cable Guide Assembly
55 Hitch Pin Clip
56 Washer
Description
