Evaluation Board User Guide
ORDERING INFORMATION
BILL OF MATERIALS
Table 1.
Reference
Qty
Designator
2
C1, C2
1
C3
2
C4, C5
2
C6, C12
5
C7, C8, C9, C10, C11
1
D1
1
JP1
2
JP2, JP3
2
J1, J2
2
J3, J11
6
J5, J6, J7, J8, J9, J10
1
R1
1
R2
1
R3
3
R5, R6, R7
4
R8, R13, R14, R15
3
R10, R11, R16
1
R17
1
R18
20
TP1 to TP20
1
U1
1
U2
1
U3A
Description
Capacitors, MLCC, 1 µF, 10 V, 0805, X7R
Capacitor, MLCC, 10 µF, 25 V, 0805, X5R
Capacitors, MLCC, 22 µF, 6.3 V, 1206, X5R
Capacitor, MLCC, 100 nF, 16 V, 0402, X7R
Capacitors, size 1206
LED 636 nm super red 0805 SMD
Connector header, 3 pins × 1 pin
Connector headers, 10 pins × 2 pins
Terminal block PCB connector, 4 position
Connector headers, 3 pins × 1 pin
Connector headers, 2 pins × 1 pin
Resistor, 56 kΩ, 1%, 0805, SMD
Resistor, 100 kΩ, 1%, 0805, SMD
Resistor, 3296 - 3/8" square trimming
potentiometer 50 kΩ
Resistors, 0805, SMD, no assembly
Resistors, 1.5 kΩ, 1%, 0805, SMD
Resistors, 0 Ω, 1%, 0805, SMD
Resistor, 470 Ω, 1%, 0805, SMD
Resistor, 0.150 Ω, 1%, 0805, SMD
Test point, test header, 1.0 mm hole
ADP1720
50 mA high voltage, micropower
linear regulator, 8-lead MSOP
ADP5063 linear LiFePO
battery charger with power
4
path and USB compatibility in LFCSP data
8-bit I
2
C-bus I/O port with reset
Manufacturer/Vendor
Murata
Murata
Murata
Murata
Not assembled
Lumex
Sullins Electronics
Not assembled
Tyco Electronics
Sullins Electronics
Sullins Electronics
Vishay or equivalent
Panasonic
Burns or equivalent
Not applicable
Vishay or equivalent
Vishay or equivalent
Vishay or equivalent
Rohm
Vero Technologies
Analog Devices, Inc.
Analog Devices, Inc.
NXP
Rev. 0 | Page 11 of 12
UG-595
Vendor P/N
GRM21BR71A105KA01
GRM21BR61E106MA73
GRM31CR60J226ME19
GRM155R71C104KA88
Not assembled
SML-LX0805SIC-TR
PEC36SAAN
Not assembled
282836-4
PEC36SAAN
PEC36SAAN
CRCW080556K0FKEA
ERJ-6ENF1003V
3296 W - 1 - 503 LF
Not applicable
CRCW08051K50FKEA
CRCW08050000Z0EA
CRCW0805470RFKEA
MCR10EZHFLR150
20-2137
ADP1720ARMZ-R7
ADP5063
PCA9557PW,112
