Security System
VISTA-10
SE
THIS ISSUE INCLUDES THE NEW "QED" (QUICK ENROLLMENT
OF DEVICES) PROCEDURE FOR 5800 SERIES TRANSMITTERS
Installation Instructions • Installation Instructions • Installation Instructions
N7227V5 5/97
www.PDF-Zoo.com
firealarmresources.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISTA-10SE and is the answer not in the manual?

Questions and answers

Related Manuals for ADEMCO VISTA-10SE

Summary of Contents for ADEMCO VISTA-10SE

  • Page 1 Security System VISTA-10 THIS ISSUE INCLUDES THE NEW “QED” (QUICK ENROLLMENT OF DEVICES) PROCEDURE FOR 5800 SERIES TRANSMITTERS Installation Instructions • Installation Instructions • Installation Instructions N7227V5 5/97 www.PDF-Zoo.com firealarmresources.com...
  • Page 2 RECOMMENDATIONS FOR PROPER PROTECTION The following recommendations for the location of fire and burglary detection devices help provide proper coverage for the protected premises. Recommendations For Smoke And Heat Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Section 1. GENERAL DESCRIPTION .................... 9 Section 2. INSTALLING THE CONTROL ................... 11 Mounting the Cabinet ....................... 11 Installing the Lock (if used) ....................11 Installing the Control's Circuit Board Alone or (if used), With a 4204 Relay Unit....11 Installing Control and RF Receiver Circuit Boards Together in the Cabinet.....
  • Page 4 Section 5. WIRELESS (RF) ZONE EXPANSION (5700 & 5800 RF SYSTEMS), CONT’D To Either Temporarily or Permanently Remove a Zone From the System (5800 System) ......................37 Deleting a Transmitter Serial Number From a Zone in 56 Mode (5800 System) ... 37 Check-out Procedure for Wireless Zones ................
  • Page 5 Section 13. SEQUENTIAL MODE (For 5800 Series Wireless Transmitters) ............61 Section 14. SYSTEM COMMUNICATION ..................64 Report Code Formats ....................... 64 Table of Contact ID Event Codes................66 Communication Programming ..................66 Section 15. TESTING THE SYSTEM ..................... 71 Test Procedure .........................
  • Page 6 LIST OF FIGURES Figure 1. Installing the Cabinet Lock ................11 Figure 2. Installing The PC Board Alone, or (if used), With a 4204 Relay Unit..... 12 Figure 3. Installing the PC Board & RF Receiver Together in the Cabinet ....12 Figure 4.
  • Page 7 “Data Field Descriptions” in the separate PROGRAMMING GUIDE that has been supplied. If you are an experienced user of Ademco products, you may choose to wire and then program the entire system at one time. If so, refer to “Mechanics of Programming”...
  • Page 8 (00 = Quit) When programming the system, data fields are indicated by a “star” [ ] followed by the data field number. PRODUCT MODEL NUMBERS: Unless noted otherwise, references to specific model numbers represent Ademco products. – 8 – www.PDF-Zoo.com firealarmresources.com...

  • Page 9: General Description

    Section 1. GENERAL DESCRIPTION The VISTA–10SE is a control that supports up to 22 zones, using basic hard-wired, and/or wireless, plus remote keypads. Basic Hardwired Zones Provides 6 basic hardwired zones having the following characteristics: (1–6) • Zones 1-6 response time is 300–500 milliseconds. •...
  • Page 10 • The system can be uploaded, downloaded, or controlled via an IBM compatible computer, using either Ademco’s V-Link ® downloading software (Rev. 4 or higher) or Ademco’s Compass Windows downloading software, and a HAYES modem specified by Ademco. Keypad programming consists of: •...

  • Page 11: Installing The Control

    LED in the receiver after it is operational). Random flicker is OK. Installing the Lock (if used) Use an Ademco No. N6277 Cam Lock and No. N6277–1 Push-On Clip (Retainer Clip). Note: The cabinet can be closed and secured without a lock by using 2 screws in the cover's edge.

  • Page 12: Figure 2. Installing The Pc Board Alone, Or (If Used), With A 4204 Relay Unit

    4204 Relay Unit 1. Insert self-tapping screws (provided) in two adjacent raised cabinet tabs. Leave the heads projecting 1/8". (if installed in cabinet) 2. Hang the unit on the screw heads via two of the slotted holes at the rear of its housing, as shown in Figure 2.

  • Page 13: Installing Control And Rf Receiver Circuit Boards Together In The Cabinet

    the Control and RF Receiver Circuit Boards Together in the Cabinet Installing 1. Hang two short (black) mounting clips (provided with receiver) on the raised cabinet tabs, as shown in Detail B in Figure 3. 2. Insert the top of the receiver board (removed from its own case as de- scribed in its in struc tions) into the slots at the top of the cabinet, as shown in Detail A in Figure 3.

  • Page 14: Wiring The Ac Transformer

    Wiring The AC Transformer No. 1321 Wire the No. 1321 transformer to terminals 1 and 2 on the control board. See wiring table below for wire gauge to use. WIRING TABLE Distance of Transformer Wire Gauge From the Control Panel To Use Up to 50 feet # 20...

  • Page 15: Installing Remote Keypads

    Section 3. INSTALLING REMOTE KEYPADS This section lists the wired keypads that may be used and provides instructions for wiring and mounting the keypads. A preliminary check-out procedure is also provided to ensure that the connected keypads are functioning properly in the system. Keypads That May Be Used •...

  • Page 16: Mounting The Keypads

    KEYPAD CONNECTOR CABLE ↓ BLACK KEYPADS GREEN YELLOW CONTROL TERMINALS Figure 5. Keypad Connections To The Control Board Mounting the Keypads 1. Make sure addressable type keypads (4137AD, 5137AD, 6128, 6137, 6138, and 6139) are set to non-addressable mode (address 31), which is the factory default setting.

  • Page 17: Preliminary Check-Out Procedure

    SUPPLEMENTARY CONTROL POWER SUPPLY TERMINAL STRIP – AUX AUX. DATA DATA – IMPORTANT: MAKE THESE CONNECTIONS DIRECTLY TO SCREW TERMINALS AS SHOWN. Figure 6. Using A Supplementary Power Supply For Keypads Preliminary Check-out Procedure If you want to check that the system is working before connecting field wiring from zones and devices, do the following: 1.

  • Page 18: Basic Hard-Wired Zones 1-6

    Section 4. BASIC HARD-WIRED ZONES 1–6 This section provides general information for the hard-wired zones in the system, plus specific instructions for installing 4-wire smoke/combustion detectors. Also included is a procedure for programming the hard-wired zones. Installing the Hard-Wired Zones Common Characteristics for Zones 1–6 •...

  • Page 19: Compatible 4-Wire Smoke/Combustion Detectors

    Compatible System Sensor 4-Wire Smoke/Combustion Detectors 1412 4-wire ionization products of combustion detector. 2412 4-wire photoelectric smoke detector. 2412TH 4-wire photoelectric smoke detector w/135°F (57°C) heat detector. A77–716B EOL relay module (supervisory module for wired 4-wire fire zone). 2112/24T Low-profile 4-wire photoelectric smoke detector w/135°F (57°C) heat detector.

  • Page 20: Programming Panic Keys

    Zone Types 00 = Zone Not Used 08 = 24 Hr Aux 01 = Entry/Exit #1 09 = Fire 02 = not used 10 = Interior w/Delay 03 = Perimeter 20 = Arm Stay* 21 = Arm-Away* 04 = Interior Follower 22 = Disarm* 05 = Trouble Day/Alarm Night 23 = No Alarm...

  • Page 21: Check-Out Procedure For Hard-Wired Zones 1-6

    When you have programmed all the hard-wired zones and Panic keys satisfactorily, exit 56 interactive mode at the Enter Zn Num. prompt by entering [ 0] [ 0] as the next zone number. Then exit the programming mode by keying 99. See the special notes below, then proceed to the check-out procedure that follows.

  • Page 22: Wireless (Rf) Zone Expansion (5700 & 5800 Rf Systems)

    Wireless may not be used in UL Commercial Burglary installations. Wireless Systems Available The VISTA-10SE supports wireless zones which may be used exclusively, or in addition to hardwire zones 1 through 6. The system supports two different wireless systems which have many similarities, but notable differences in the programming of the transmitters for each system.

  • Page 23: Transmitter Battery Life

    The supervision for a particular transmitter in the 5800 system may be turned off by entering it as a "UR" (unsupervised RF) type, as described later. 5800 series transmitters have built-in tamper protection and will cause a “CHECK” condition to be annunciated if covers are removed. Each transmitter is also supervised for low battery and will transmit a low bat- tery signal to its receiver, with the battery having at least 30 days of life remain- ing.

  • Page 24: Installing The 5800Tm Module

    Terminal 7 BLUE: Not Used Do not cut any of the jumpers on the 5800TM when using it with the VISTA-10SE. For additional information, refer to the 5800TM’s instructions. 5700 Series Transmitter Setup Each 5700 series transmitter has DIP switches to set both the transmitter's zone number (Transmitter zone/ID) and the system House ID.

  • Page 25: Setting The Dip Switches On 5700 Series Wireless Transmitters

    Setting the DIP Switches Set the DIP switches on each 5700 series transmitter to the appropriate on 5700 Series zone/ID number and House ID. Refer to the Compatible 5700 Series Transmitters Transmitters table on a following page in this section for zone numbers and programming information for each particular transmitter.

  • Page 26: Dip Switch Tables For 5700 Rf System Wireless Devices

    DIP SWITCH TABLES FOR 5700 RF SYSTEM WIRELESS DEVICES 5775 PIR HOUSE ID 5701 PANIC TRANSMITTER 5706/5707 SMOKE DETECTOR/TRANSMITTER SWITCH SETTING FOR ALL DETECTORTRANSMITTER DEVICES EXCEPT 5716 MIRROR HOUSE ID (1 SHOWN) DIP SWITCH POSITION DEVICE SIDE 1 2 3 4 5 6 VIEW (UP) —...

  • Page 27: Compatible 5700 Series Transmitters

    Compatible 5700 Series Transmitters Model Product Zone/ID # Description 5701 Panic Transmitter 62 or 63 • Programmable for either silent or audible 24-hour alarm. 5706 Photoelectric Smoke 48–55 • One-piece smoke detector with Detector built-in transmitter. • Built-in UL Listed 85dB piezo electric alarm sounder and audible low battery warning.

  • Page 28: Programming The Control For A 5700 Wireless System

    Programming the Control For a 5700 Wireless System 1. With at least one two-line Custom English keypad wired and set to address 31 (default), power up the system temporarily by plugging the AC transformer (previously wired to the control) into a 120VAC outlet. 2.
  • Page 29 Data field 22 RF SYSTEM TYPE, must have been programmed for a 5700 RF system (“1”). Also, the House ID should have been entered in field 24, and all 5700 transmitters set to the same House ID. 4. Press 56. (Zone Programming Mode) Use this mode to program zone numbers, zone types, and alarm report codes for all 5700 wireless zones that are going to be used in the system.

  • Page 30: Go/Nogo Test

    10. Mark the zone number on the transmitter. 11. After the transmitter has been entered into the system, press [ ] to continue. Typical summary display A summary of the programmed values for the Zn ZT – RC In: selected zone will now be displayed 20 03 –...

  • Page 31: 5800 Series Transmitter Setup

    • If the keypad does not beep, re-orient or move the transmitter to another location. Usually a few inches in either direction is all that is required. 3. Mount the transmitter according to the instructions provided with the transmitter. 4. Exit the GO/NO GO test mode by entering Installer Code + (OFF). You should now proceed to “Check-Out Procedure for Wireless Zones”...

  • Page 32: Compatible 5800 Series Transmitters

    Compatible 5800 Series Transmitters Enter As Input Model Product Device Type Description 5801 Wireless Panic UR or RF • Has four pushbuttons, each with a Transmitter unique input (loop) code. • Programmable responses (e.g., Panic, Arm–Stay, Arm–Away, Disarm, etc. 5802 Pendant BR Only •...

  • Page 33: Programming The Rf Transmitters (5800 Rf Systems)

    Compatible 5800 Series Transmitters (Continued) Enter As Input Model Product Device Type Description 5819 Shock Processor • Connects to externally mounted Transmitter inertia-type shock detector (not supplied). • Has built-in tampered cover switch. • Has 3 unique input (loop) codes: Loop 1: Terminals for a wired, N.C.

  • Page 34: Enrolling 5800 Transmitters Into The System

    24. RF HOUSE ID CODE The House ID identifies a 5827 or 5827BD Wireless keypad if it is used (enter 01–31). The wireless keypads should be set to the same ID. If no wireless keypad is to be used, leave as “00”. Enrolling 5800 Transmitters Into The System There are two methods that may be used to enroll transmitters.
  • Page 35 A display will appear, showing a summary of that zone's programming. ZN ZT – RC I n : L If the zone is not programmed, the display will appear as shown here. If 1 0 0 0 – 0 0 RF : 1 checking a zone's programming, and it is programmed satisfactorily, press [#] to back up one step and enter another zone number, if desired.
  • Page 36 The system will enroll the serial number of the first transmitter heard, 10 Input S/N: add the loop number entered to this serial number, display the serial A002-4064 and loop numbers, and cause the keypad to beep twice. If the serial and loop number combination is already present in the system, a single long beep will be heard from the keypad.

  • Page 37: To Either Temporarily Or Permanently Remove A Zone From The System (5800 System)

    To Either Temporarily Or Permanently Remove A Zone From The System (5800 System). 1. Enter the programming mode: Key Installer Code + 8 + 0 and press [ ][5][6]. 2. Enter the zone number and press [ ]. A summary display will appear. 3.
  • Page 38 Go/No Go Test Before mounting transmitters permanently, conduct Go/No Go tests to verify (5700/5800 adequate signal strength and reorient or relocate transmitters if necessary. RF Systems) During this mode, wireless receiver gain is reduced by 50%. Testing in this mode assists in determining good mounting locations for the transmitters and verifies that the RF transmission has sufficient signal amplitude margin for the installed system.

  • Page 39: Relay Output Devices

    Section 6. RELAY OUTPUT DEVICES Relay Device Basics Relays are programmable switches that can be used to perform many different functions. They can be used to turn lights on and off, control sounders, or for status indications. In this system, each relay must be programmed as to how to act (ACTION), when to activate (START), and when to deactivate (STOP).
  • Page 40 The letter(s) in parentheses after each function described below, such as (A) after ACTION, are those that appear in the various summary displays of programmed data during programming. ACTION (A) The "ACTION" of the relay is how the relay will respond when it is activated by the "START"...

  • Page 41: Programming Output Relays

    STOP (STP): The "STOP" programming determines when and under what conditions the relay will be de-activated. The following options are available: 1. RESTORE ZONE LIST (ZL). If a "ZONE LIST" is used as the “Stop” event, the relay will de-activate when all the zones in that list restore from a previous fault, trouble, or alarm condition.
  • Page 42 Output Relay Displays Upon pressing 80, this screen will appear. Enter the Relay Number 01, 02, Enter Relay No. 03, or 04 for a 4204 (or 00 to end these entries). Press the [ ] key to (00 = Quit) continue.

  • Page 43: Example Of Output Relay Programming

    The display then returns again to the first screen so that the next relay number to be programmed can be entered, or enter [0][0] to end relay programming. Previously entered data can be reviewed by pressing [#] [8] [0]. After the relay number is chosen, press [ ] to go to the next screens.

  • Page 44: 4285 Phone Module

    Section 7. 4285 PHONE MODULE This section provides instructions for mounting the 4285 Phone module, wiring the Phone module and for programming the system for phone access via the Phone module. Installing the Phone module General Information The 4285 Phone module is an add-on accessory for the VISTA–10SE that permits access to the security system via a Touch-tone phone (either on premises or by a call-in when away).

  • Page 45: Caller Id Units

    1. Make 12V (+) and (–) and data in and data out connections from the Phone module to the control, using the connector cable supplied with the Phone module (see Figure 10). These are the same connections Color Lead Terminal On Control * as those used for remote GREEN DATA IN (terminal 6)

  • Page 46: Figure 10. 4285 Phone Module Wiring Connections

    4285 WIRING NOTES: 1. Wire the 4285 Phone module exactly as shown, using a direct-connect cord and RJ31X jack. 2. If Touch-tones are not heard when pressing keys following phone access to the security system via an on-premises phone , try reversing the pair of wires connected to terminals 3 & 4 on the 4285, and the pair of wires connected to terminals 17 &...

  • Page 47: Programming The Control For Phone Access

    Programming The Control For Phone Access 1. With at least one addressable keypad (but set to the non-addressable mode, address 31) connected to the keypad terminals on the control, power up the system temporarily. If you had previously connected the AC transformer to the control panel, you need only plug in the transformer (to 120VAC outlet) to power up the system.

  • Page 48: Checking The Operation Of The 4285 Phone Module

    Checking the Operation of the 4285 Phone module To Check Phone module Operation From an On-Premises Phone 1. Pick up phone and enter the programmed 2-digit phone code (entered in field . Annunciation of a VOICE (PHONE) MODULE ACCESS CODE) system status report should automatically start.

  • Page 49: External Sounders

    This section provides a list of compatible sounders, connection information for an external sounder and programming procedures for those options that affect the operation of external sounders. Compatible Sounders Ademco AB-12M 10” Motor bell & box. UL Grade A. 100mA current Motorized Bell & Box draw.

  • Page 50: Sounder Connections

    This control complies with NFPA requirements for temporal pulse sounding of fire notification appliances. Temporal pulse sounding for a fire alarm consists of the following: 3 pulses – pause – 3 pulses – pause – 3 pulses. . . repeated. Sounder Connections The VISTA–10SE provides a 12 VDC output which can power external alarm sounders (bells or sirens, see compatible sounders listed previously).

  • Page 51: Long Range Radio

    Section 9. LONG RANGE RADIO General Information Check availability of Model 7720PLUS or 7820 long range radio. If output to long range radio is selected, all messages that are programmed to go to the primary telephone line receiver will also be sent to the 7720PLUS or 7820 long range radio.

  • Page 52: Audio Alarm Verification (Aav) Unit

    Section 10. AUDIO ALARM VERIFICATION (AAV) UNIT General Information An Audio Alarm Verification (AAV) module, such as the Eagle 1241 , is an add- on accessory that permits voice dialog between an operator at a central station and a person at the alarm installation, for the purpose of alarm verification. Alarm reports must be programmed for the primary phone number to enable this feature.

  • Page 53: Figure 13. Connection Of Aav Unit When Not Using A 4285 Phone Module

    INCOMING TELCO LINE DIRECT CONNECT CORD RJ31X RING PREMISES JACK ANSWERING MACHINE AND PLUG PHONES ANSWERING TERMINALS MACHINE 17 18 ON CONTROL EARTH GROUND REFER TO AAV MODULE INSTRUCTIONS FOR CONNEC- TIONS TO AUDIO SPEAKERS AND MICROPHONE INPUT TRIGGER RING 4204 MODULE NOTE:...

  • Page 54: Final Power Up

    Section 11. FINAL POWER UP In previous sections, you made temporary power connections for the purpose of programming and testing. This section provides information about final power-up procedures and battery size calculations. Earth Ground Connections The designated earth ground terminal (21) must be terminated in a good earth ground for the lightning transient protective devices in this product to be effective.

  • Page 55: Making The Battery Connections

    Making the Battery 1. Use the battery standby formula (shown on previous page) to select the Connections appropriate battery for the installation. Remember, when calculating the battery size needed, you must add the 100mA drawn by the control itself to the total Auxiliary current draw in the worksheet below.

  • Page 56: Alpha Descriptor Programming

    Section 12. ALPHA DESCRIPTOR PROGRAMMING This section provides instructions for programming Alpha descriptors This is recommended for systems using Alpha keypads, and necessary if a 4285 Phone module is used. Alpha descriptors cannot be displayed on fixed-word keypads. If using a 4285 Phone module, select from those words in the Alpha Vocabulary list (on a following page) shown in boldface type.
  • Page 57 4. Press “0” (No).* The system will then automatically display the default descriptor for zone 1. The procedure for adding custom words to the built-in vocabulary will be found later under “Adding Custom Words”. Default Descriptor ↓ If a descriptor was not entered previously for zone 1, the default descriptor for zone ZN 0 1 ZO NE 0 1...

  • Page 58: Alternate Method For Programming Zone Descriptors

    9. Press “6” to accept the selected ZN 0 1 BA CK word. DO O R Note: If these are the only words you are using for the descriptor, ↑ press “8” instead of “6” to save them Flashing Cursor if “6” is in memory.

  • Page 59: Adding Custom Words

    4. For selection of the next word (e.g., DOOR), repeat step 3, as follows: Press key [3] until the first letter of the next word appears (e.g., "D"). Then press [6] to display the first available word beginning with that letter (e.g. DAUGHTERS).

  • Page 60: Alpha Vocabulary List (For Entering Zone Descriptors)

    ALPHA VOCABULARY LIST (For Entering Zone Descriptors) NOTE : Some rarely-used words appearing in previously published lists have been deleted from the list below. Use only this list for selecting zone descriptors. (Word Space) • 057 DOOR • 106 LAUNDRY •...

  • Page 61: Sequential Mode

    Section 13. SEQUENTIAL MODE (for 5800 Series Wireless Transmitters) (Use this mode only after all other zone information has been programmed, including transmitter loop numbers). There are two methods of enrolling – you can enroll each transmitter into the system as you are entering the zone information in field 56 (the procedure will be found in the WIRELESS (RF) ZONE EXPANSION section), or you can enroll all the transmitters in 83 menu mode after all other zone...
  • Page 62 5. This prompt is displayed when the system has found the next zone 10 Input S/N: which needs to be enrolled. Axxx xxxx The system will respond to the first serial number transmitted. A serial number may be enrolled by one of two methods: a) Enter the 7 digit serial number printed on the transmitter b) Activate the transmitter by faulting or restoring the input you wish to use for that zone (e.g., press a button, open or close a door, etc.).
  • Page 63 7. The system will search for the next zone that does not have a serial number associated with it. If one is found, the prompt in step 5, along with the appropriate zone number, will be displayed. Follow steps 5 and 6 for the remaining wireless zones.

  • Page 64: System Communication

    This is the “expanded” digit. 4+2 Format Comprises a 4-digit subscriber number and 2-digit report code. Ademco Contact ID Comprises a 4-digit subscriber number, 1-digit event qualifier Reporting Format ("new" or "restore"), 3-digit event code, and 3-digit zone number, user number, or system status number (see the following page).
  • Page 65 [1] + [ ], or [A] = 95 Duress = 8 [3] + [#], or [C] = 96 Tamper = 9 Ademco Contact ID Reporting takes the following format: CCCC Q EEE GG ZZZ where: CCCC = Customer (subscriber) ID Q = Event qualifier, where:...

  • Page 66: Table Of Contact Id Event Codes

    TABLE OF CONTACT ID EVENT CODES Code Definition Code Definition Fire Alarm Exit Error Alarm Duress Trouble (Global) Alarm, 24-hour Silent RF Sensor Tamper Alarm, 24-hour Audible Panic RF Sensor Low Battery Alarm, Perimeter, Burg. O/C by User Alarm, Interior, Burg. Cancel by User Alarm, Entry/Exit, Burg.
  • Page 67 REPORT FORMAT, PRIMARY/SECONDARY Determines which format is to be used to report to the central station. 0 = 3+1; 4+1 ADEMCO Lo Speed Standard (this is the default) 1 = 3+1; 4+1 Radionics Standard 2 = 4+2 ADEMCO Lo Speed Standard...
  • Page 68 A "0" ( not "# + 10") in both boxes will disable the report. With Ademco Contact ID Reporting: Enter any digit (other than "0") in the first box, to enable zone to report This is an "enabling" code only and is disregarded in the actual reporting to the central office.
  • Page 69 Press 63 LOW BAT REPORT CODE This will be sent when a low battery condition exists in the system’s standby battery. Note: Connection to the standby battery is checked every 3 minutes (CSFM requirement). Press 64 TEST REPORT CODE This is sent periodically to test that the communicator and phone lines are operational (frequency of report is selected in field 51).
  • Page 70 Press 74 LOW BAT RESTORE REPORT CODE This is sent when a system low battery condition is restored to normal. Press 75 RF XMTR. LOW BATTERY RESTORE CODE This is sent when a transmitter that previously sent in a low battery message has sent a message indicating it no longer has a low battery condition.

  • Page 71: Testing The System

    Section 15. TESTING THE SYSTEM Test Procedure After installation is completed, the System should be carefully tested, as follows: 1. With the System in the disarmed state, check that all zones are intact. If a NOT READY message is displayed, press the [ ] key to display the faulted zone(s).

  • Page 72: To The Installer

    To test the wireless part of the system and the RF Receiver, perform the two following tests: Transmitter Sniffer Mode and Go/NoGo Test Mode . TRANSMITTER SNIFFER MODE Make sure the system is disarmed before trying to enter this mode. Key Installer code + # + 3.

  • Page 73: System Operation

    Section 16. SYSTEM OPERATION Security Codes Installer Code The installer programs the 4-digit Installer Code initially as part of the programming procedure. The factory default Installer code is "4-1-1-1", but may be changed in field 20. Note: The Installer Code is defined as User #1. The Installer code is the only code that can allow re-entry into programming mode.

  • Page 74: Keypad Functions

    Keypad Functions General Note that if you enabled QUICK ARM (field 21), the [#] key can be pressed Information instead of entering the security code, for any of the arming procedures (Away, Stay, Instant, Maximum, etc.). The security code is always required, however, when disarming the system.

  • Page 75: Panic Keys

    Panic Keys There are three individual panic keys or, on some keypads, panic key pairs. If programmed, they can be used to manually initiate alarms and send a report to the central station. Each key (or key pair) can be individually programmed for 24-hour Silent, Audible, Personal or Fire Emergency responses.

  • Page 76: Trouble Conditions

    • The " " display, etc. will also result if an alarm from an exit or EXIT ALARM interior zone occurs within two minutes after the end of an exit delay. In any of the previous cases, use a second OFF sequence (code plus OFF key) to clear the display.

  • Page 77: Troubleshooting Guide

    Section 17. TROUBLESHOOTING GUIDE SYSTEM (including Wireless) SYMPTOM POSSIBLE CAUSE REMEDY 1. Transmitter signal not 1a. Transmitter or 4281/5881 not properly pow- Check or change transmitter's bat tery. received at 4281/5881. ered. Check the control's AC power. 1b. If Transmitter is 5827/5827BD , house ID 1b.
  • Page 78 TROUBLESHOOTING GUIDE (continued) SYMPTOM POSSIBLE CAUSE REMEDY 7. Intrusion alarm for no ap- 7d. Magnetic contacts improperly connected or 7d. Check wiring connections. Be sure wires parent reason. (continued) wire broken. are properly stripped and are tightly fastened to screw terminals. 7e.

  • Page 79: Contacting Technical Support

    (1200 – 9600 Baud, 8 Data Bits, 1 Start/Stop Bit, No Parity) ATLIS FAX – Automated Fax Retrieval System: 1–800–573–0153 1–516–921–6704/Ext. 1667 ADEMCO World Wide Web Page: HTTP//: WWW. ADEMCO. COM INTERNET E-Mail Address: Ademco_Tech_SPRT @ Ademco–165 . Ademco . com – 79 – www.PDF-Zoo.com firealarmresources.com...

  • Page 80: Specifications & Accessories

    1. Physical: 12-1/2" W x 14-1/2" H x 3" D (318mm x 368mm x 76mm) SECURITY CONTROL 2. Electrical: VOLTAGE INPUT: 16.5VAC from plug-in 25VA transformer, Ademco No. 1321/TF2 (in U.S.A.) RECHARGEABLE BACK-UP BATTERY: 12VDC, 4AH (Gel type). Charging Voltage: 13.8VDC.
  • Page 81 200ft (60m) nominal indoors from wireless transmitters (the (5800 System) actual range to be determined with system in TEST mode). (With the Ademco VISTA–10SE ) 5. Zones: 4281L (4281CN-L*): accepts up to 4 transmitters. 4281M/ 4281H (4281CN-H*): accepts up to 8 transmitters.

  • Page 82: Accessories (Compatible Devices)

    No. 1321 16.5VAC, 25VA Plug-In Transformer (in U.S.A.) No. 1321CN 16.5VAC, 25VA Plug-In Transformer (in Canada) Sounders Ademco AB-12M 10” Motor bell & box. UL Grade A. 100mA current Motorized Bell & Box draw. Ademco 1011BE12M 10” Motor bell & box. UL Listed. 100mA current Motorized Bell &...

  • Page 83: Regulatory Agency Statements

    REGULATORY AGENCY STATEMENTS FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information: This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception.
  • Page 84 500mA 17.2AH NPG18-12 ‡ Note: Use two batteries, connected in parallel. Obtain an Ademco Battery Harness kit. A dual battery harness is provided with the kit. Both batteries will fit inside the panel's cabinet. – 84 – www.PDF-Zoo.com firealarmresources.com...
  • Page 85 CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC) STATEMENT NOTICE The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.

  • Page 86: Limitations Of This Alarm System

    WARNING! THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced design security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of rea sons. For example: •...
  • Page 87 USED, BUT USE MAX. OF 220 FT. WARNING: OWNER'S INSTRUCTION NOTICE NOT TO BE REMOVED. WEEKLY TESTING IS TO A POLICE EMERGENCY NUMBER. OF #22 WIRE OR 550 FT. OF #18. REQUIRED TO ENSURE PROPER OPERATION OF THIS SYSTEM. ADT VISTA-10SE SUMMARY OF CONNECTIONS firealarmresources.com...

  • Page 88: Limited Warranty

    24 months from the date stamp control on the product or, for products not having an Ademco date stamp, for 12 months from date of original purchase unless the installation instructions or catalog sets forth a shorter period, in which case the shorter period shall apply.
