ADEMCO VISTA-10P Programming Manual

Alarm control panel
Hide thumbs Also See for VISTA-10P:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
9,67$3
3URJUDPPLQJ*XLGH
AR ME
D
RE AD Y
OFF
ON
®
K0735PRV1 9/02

Advertisement

Table of Contents
loading

Related Manuals for ADEMCO VISTA-10P

Summary of Contents for ADEMCO VISTA-10P

  • Page 1 9,67$3 3URJUDPPLQJ*XLGH AR ME RE AD Y ® K0735PRV1 9/02...

  • Page 2: To Enter Programming Mode

    TO ENTER PROGRAMMING MODE: Local programming requires the use of an alpha keypad connected to the keypad terminals on the control. A. POWER UP, then depress [ ] and [#] both at once, within 50 seconds of powering up )if 98 was used to exit previously, this method must be used to reenter program mode).

  • Page 3: System Setup

    ∗35 Report Format Entry Delay #1 [77] (zone type 01) [30] 0 = 3+1, 4+1 ADEMCO L/S STANDARD Primary Second 00 - 96 = 0 - 96 seconds 1 = 3+1, 4+1 RADIONICS STANDARD 97 = 120 seconds SIA Installations:...

  • Page 4: System Status Report Codes

    1 = 30 seconds 7 = 3 min #+13 = 10 min For Ademco Contact ID® Reporting: Enter any digit (other than 0) 2 = 45 seconds 8 = 4 min #+14 = 12 min in the first box, to enable zone to report (entries in the second boxes...
  • Page 5 Multiple choice example: for AAV (4) + Exit Delay restart (8) enter # + 12. 0 = None ∗182 Configurable Zone Type 90 4 = AAV UL: must use ADEMCO UVCM module 8 = Exit Delay Restart/Reset UL: must be disabled SIA Installations: Exit Delay should be enabled. ∗93...
  • Page 6 Configurable Zone Types Worksheets Configurable zone type 90 can be programmed via downloader software or from a keypad using data fields*182- *183. Programming Configurable Zone Type options involves making 10 entries in data field *182, where each entry represents the sum of the values of the various options shown in the tables below. Use field *183 to program a Contact ID report code for this zone type.
  • Page 7 *56 ZONE PROGRAMMING WORKSHEET [default shown in brackets] Zone Zn Type Part. Report Hardwire Rsp. Time Location Type [01] [EOL] [01] [EOL] [03] [EOL] [03] [EOL] NOTES: [03] [EOL] Zone Type: see chart on page 11; [03] [EOL] Zone Zn Type Part.

  • Page 8: Wireless Key Predefined Default Templates

    This prompt appears only for hard-wired zones 01-06 (zone 02 is used as an example in display). 02 Response Time Enter the desired response time for this zone: 0 = 10mSec; 1 = 350mSec; 2 = 700mSec; 3 = 1.2 seconds [∗] to continue This prompt is skipped for zones 1-6.

  • Page 9: Expert Programming Mode Procedures

    ∗58 Expert Programming Mode Procedures (press ∗58 while in Data Programming mode) We recommend that you select “yes” to confirm the programming of every transmitter. SET TO CONFIRM? If selected, a prompt appears after entering the serial and loop numbers to confirm each transmitter) 0 = NO 1 = YES A summary screen will appear, showing zone 1’s currently programmed values.
  • Page 10 *57 FUNCTION KEY PROGRAMMING Option Function Comments Paging Time Display Arm AWAY Arm STAY Arm NIGHT-STAY Step Arming Device Activation Device: Comm. Test Macro Key Emergency Keys: zone 95 zone 99 zone 96 paging Personal Emergency Silent Alarm Audible Alarm Fire Emergency Keys: A = paired keys [1] / [∗] (zone 95);...

  • Page 11: Output Definitions

    80 OUTPUT DEFINITIONS Output Activation Type and Detail Event (for zone list/activated by) Action Output Device Function 0 = off Number Type Activated by Zone List Zone Type Zone No. By Zone List By Zone No. Number 1 = close 2 secs 0=delete (ZL) (ZT)

  • Page 12: Zone Lists

    “C” If zone number was selected, this screen appears. 01 Enter Zn No. Enter the desired zone number associated with this output number. Press [∗] to continue. Enter the zone event that will activate this output. 01 Enter Event 0 = restore; 1 = alarm/fault/trouble Restore Press [∗] to continue to the “Output Action”...

  • Page 13: Alpha Vocabulary List (For Entering Zone Descriptors)

    ALPHA VOCABULARY LIST (For Entering Zone Descriptors) • 057 DOOR ∗ (Word Space) – L – – R – – V – • 106 LAUNDRY ∗ RADIO VALVE – A – • 059 DOWN VAULT • 107 LEFT • 156 REAR •...
  • Page 14 Start Zone Descriptor Programming mode by pressing *82 while in Data Programming mode. Press 1 to program descriptors. P r o g r a m A l p h a ? 0 = exit this mode 0 = N o , 1 = Ye s To program standard alpha descriptors from the fixed vocabulary, press 0.
  • Page 15 Schedules (installer code + [#] + [6] [4]; master code can only access schedules 01 and events 00-07 ) Event Device No. Group No. Start Time/ Stop Time/ Repeat Random Days Days (see list below) for “01” events: for “02” events: (1-4) (yes/no) enter 01-04...

  • Page 16: 5800 Series Transmitter Input Loop Identification

    5800 Series Transmitter Input Loop Identification Transmitters illustrated have one or more unique factory LOOP 3 LOOP 2 assigned input (loop) ID codes. Each of the inputs LOOP (REED) LOOP (REED) (PRIMARY) requires its own programming zone (e.g., a 5804's four LOOP 2 LOOP 1 (TERMINALS)
