Installation
The battery is connected to Performance Box Touch with a Richter mounting system on the rear of the unit. Insert
the prongs from the back of the battery into the rear of the Performance Box Touch unit and push upwards to
secure.
Richter mounting system on the rear of battery
Richter mounting system on the back of
(RLACS290)
Performance Box Touch
Performance Box Touch comes supplied with a Suction Cup Windscreen Mount (ACS318MOUNT) so you can
mount it on the vehicle's windscreen. It attaches to the Richter mounting system on the back of the unit, or at the
back of the
Battery
if this is connected to the unit.
https://en.racelogic.support//Product_Info/Performance_Meters/Performance_Box_Touch/Performance_Box_Touch_V2/
Quick_Start_Guide_%E2%80%93_Performance_Box_Touch_V2/Quick_Start_Guide%3A_Decel_Mode_-
_Performance_Box_Touch_V2
6
