Mechanical Installation 49-
3.5.3

Laminar air purge for CoolingJacket

Laminar air purge for front mounting of the
CoolingJacket Advanced (Standard and Extended).
Two different versions are available: One for
standard IR camera applications [Part-No.:
ACCJAAPLS] and the other for line scanning
applications [Part-No.: ACCJAAPLL].
Those two versions are fitting to all focusing units
with production date ≥01/2018. A protective window
(67 x 3 mm) has to be ordered separately. If you like
to mount the air purge on an older CJ, the focusing
unit should be exchanged to the current version.
