optris PI 200 Operator's Manual page 18

-
18
Temperature ranges
Sighting range
2)
Spectral range
Detector
Lenses (FOV)
Microscope lens (FOV)
System accuracy
3)
Thermal sensitivity (NETD):
Warm-up time
Emissivity
Software
1)
Accuracy statement effective from 150 °C
2)
The sighting range is used to align the G7 cameras

3)
At ambient temperature 23
PI 640
-20...100 °C; 0...250 °C; (20) 150...900 °C
Option: 200...1500 °C
-
7.5 - 13 µm
15° x 11° (F=1); 33° x 25° (F=0,8); 60° x 45° (F=0,8); 90° x 64° (F=0,8)
12° x 9° (F=1,1)
75 mK with 33°, 60° and 90°
85 mK with 15°
5 °C; whichever is greater
PI 640 G7
200...1500 °C
1)
150...900 °C
0...250 °C
7,9 µm
UFPA,
640 x 480 Pixel @ 32 Hz
640 x 120 Pixel @ 125Hz
-
±2°C or ±2 %
130 mK (T = 650 °C)
obj
10 min
0.100...1.100
PIX Connect
-
