Mechanical Installation
3 Mechanical Installation
3.1 Dimensions
The PI is equipped with two metric M4 thread holes on the bottom side (6 mm depth) and can be installed
either directly via these threads or with help of the tripod mount (also on bottom side).
The tightening torque of the M4 screws for mounting the PI camera should be between
1 ... 1.5 Nm and must not exceed 2 Nm.
