optris PI 450i Operator's Manual

Hide thumbs Also See for PI 450i:
Table of Contents

Advertisement

Quick Links

Download this manual
Operator's Manual
1.888.610.7664
optris
400i/ 450i/ 450i G7/ 640/ 640 G7/ 05M/ 08M/ 1M
Infrared camera
www.calcert.com
15
10
20
5
25
0
30
®
PI
sales@calcert.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PI 450i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for optris PI 450i

Summary of Contents for optris PI 450i

  • Page 1 Operator’s Manual optris ® 400i/ 450i/ 450i G7/ 640/ 640 G7/ 05M/ 08M/ 1M Infrared camera 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 2: Table Of Contents

    Table of contents Table of contents Table of contents .............................. 3 General Notes ............................7 Intended use ............................7 Warranty ............................. 8 Scope of delivery ..........................9 Maintenance ............................9 1.4.1 Cleaning ............................9 Model overview ..........................10 Technical Data ............................11 General specifications ........................
  • Page 3 Measurement specifications ......................16 Optical specifications ........................20 Mechanical Installation .......................... 29 Dimensions ............................29 Changing the lens ..........................36 Fixing the focus of the lens (only for PI 05M/ 08M/ 1M) ..............37 Mounting accessories (optional) ....................... 39 High temperature accessories ......................40 3.5.1 CoolingJacket Advanced ......................
  • Page 4 Table of contents 4.1.1 PIN allocation ..........................49 4.1.2 Industrial Process Interface (optional) ..................51 Example for a Fail-Safe monitoring of the PI with a PLC ..............54 USB cable extension ........................56 IRmobile App ............................58 Software PIX Connect ..........................60 Installation and initial start-up ......................
  • Page 5 Characteristic emissivity ........................78 Appendix A – Table of emissivity for metals ....................79 Appendix B – Table of emissivity for non-metals ..................81 Appendix C – Quick start for serial communication ................... 82 Appendix D – Interprocess Communication (IPC) ..................84 Appendix E –...

  • Page 6: General Notes

    Thank you for choosing the optris PI infrared camera. The optris PI calculates the surface temperature based on the emitted infrared energy of objects [►7 Basics of Infrared Thermometry]. The two-dimensional detector (FPA - focal plane array) allows a measurement of an area and will be shown as thermal image using standardized palettes. The radiometric processing of the picture data enables the user to do a comfortable detailed analysis with the software PIX Connect.

  • Page 7: Warranty

     Avoid abrupt changes of the ambient temperature.  Avoid static electricity, arc welders, and induction heaters. Keep away from very strong EMF (electromagnetic fields).  In case of problems or questions which may arise when you use the infrared camera, please contact our service department.

  • Page 8: Scope Of Delivery

    General Notes 1.3 Scope of delivery  PI 400i, PI 450i, PI 450i G7, PI 640, PI 640 G7, PI 05M, PI 08M or PI 1M incl. 1 lens  USB-cable: 1 m (standard scope of supply, no IP67 protection class) 1 m, 3 m, 5 m, 10 m, 20 m (optional, for industrial applications, with IP67) ...

  • Page 9: Model Overview

    -20 to 900 °C 8 – 14 µm 80 Hz Real-time thermographic images in high speed; 200 to 1500 °C (optional) Detection of smallest temperature differences (PI 450i) PI 450i G7 200 to 1500 °C 7.9 µm 80 Hz/ 27 Hz Measurement of glass (with Line-Scanning mode) 150 to 900 °C...

  • Page 10: Technical Data

    Aluminum, anodized Dimensions: PI 400i/ PI 450i (450i G7): 46 x 56 x 68 - 77 mm (depending on lens and focus position) PI 640 (640 G7): 46 x 56 x 76 - 100 mm (depending on lens and focus position) PI 640 microscope optics: 46 x 56 x 119 –...
  • Page 11 Cable length (USB 2.0): 1 m (standard), 3 m, 5 m, 10 m, 20 m Vibration IEC 60068-2-6 (sinus shaped) IEC 60068-2-64 (broadband noise) Shock IEC 60068-2-27 (25 G and 50 G) Used standards for vibration and shock: Figure 1: Used standards Stress program (camera in operation): 1.888.610.7664 www.calcert.com...
  • Page 12 Technical Data Shock, half sinus 25 G – testing Ea 25 G (acc. IEC 60068-2-27) Acceleration 245 m/s (25 G) Pulse duration 11 ms Number of directions (3 axes with 2 directions each) Duration 600 Shocks (100 Shocks each direction) Shock, half sinus 50 G –...
  • Page 13 Number of axes Duration 1:30 h (3 x 0.30 h) Vibration, broadband noise – testing Fh (acc. IEC60068-2-64) Frequency range 10 - 2000 Hz Acceleration 39.3 m/s (4.01 G Frequency spectrum 10 - 106 Hz 0.9610 (m/s (0.010 G /Hz) 106 - 150 Hz +6 dB/ Octave 150 - 500 Hz...

  • Page 14: Electrical Specifications

    Technical Data 2.2 Electrical specifications Power Supply: 5 VDC (powered via USB 2.0 interface) Current draw: Max 500 mA AO: Output Standard Process Interface recording status, line scan status, 0 - 10 V (Main measure area, measure area, internal temperature, flag status, (PIF out) alarm, frame sync, fail-safe, external communication) [►Appendix F –...

  • Page 15: Measurement Specifications

    2.3 Measurement specifications PI 400i PI 450i PI 450i G7 Temperature ranges -20...100 °C; 0...250 °C; (20) 150...900 °C ; Option: 200…1500 °C 200…1500 °C 150…900 °C Sighting range / low energy range 0…250 °C Spectral range 8 - 14 µm 7.9 µm...
  • Page 16 Technical Data PI 640 PI 640 G7 Temperature ranges -20...100 °C; 0...250 °C; (20) 150...900 °C 200…1500 °C Option: 200…1500 °C 150…900 °C Sighting range / low energy range 0…250 °C Spectral range 8 - 14 µm 7,9 µm Detector UFPA, 640 x 480 Pixel @ 32 Hz 640 x 120 Pixel @ 125Hz...
  • Page 17 PI 05M PI 08M PI 1M Temperature ranges 900 … 2450 °C (27 Hz mode) 575 …1900 °C (27 Hz mode) …1800 °C (27 Hz mode) …1800 °C (80 Hz and 32 Hz mode) 950 … 2450 °C (80 Hz and 32 Hz mode) 625 …...
  • Page 18 Technical Data Emissivity 0.100...1.100 Software / App PIX Connect / IRmobile +75 °C start temperature for optics with focal length f= 50 mm, f= 75 mm An additionally purchased lens for the PI 05M/ 08M/ 1M camera comes with the corresponding protective tube At an ambient temperature of 25 °...

  • Page 19: Optical Specifications

    2.4 Optical specifications Make sure that the focus of thermal channel is adjusted correctly. If necessary, focus the thermal imaging camera with the optics (Figure 2). The turning out of the optics leads to the focus setting "near" and the turning in of the lens to the focus setting "infinity". Figure 3: PI 05M/ PI 08M / PI 1M Figure 2: Focusing by turning the exterior lens ring of camera...
  • Page 20 They display the connection between the distance of the measured object and the size of the pixel (Table 2). ® Figure 4: Measurement field of the infrared camera optris PI 640 representing the 33° x 25° lens 1.888.610.7664 www.calcert.com...
  • Page 21 In high-performance infrared optical systems as used by Optris, this is 3×3 pixels, with lower quality optical systems, in some circumstances as many as 10×10 pixels may be required, to receive 90 % of the energy. A high-performance camera lens also allows a larger measuring distance with the same number of pixels of the detector, or the 1.888.610.7664...
  • Page 22 As an alternative to the tables below, the optics calculator can also be used on the optris website or via the optris calculator app. The app can be downloaded for free from the Google Play Store (see QR code).
  • Page 23 Table 2: * Note: The accuracy of measurement can be outside of the specifications for distances below the defined minimum distance. 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 24 Technical Data * Note: The accuracy of measurement can be outside of the specifications for distances below the defined minimum distance. 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 25 * Note: The accuracy of measurement can be outside of the specifications for distances below the defined minimum distance. 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 26 Technical Data * Note: The accuracy of measurement can be outside of the specifications for distances below the defined minimum distance. PI 05M is only available with OF25 optics and PI 08M is only available with OF16 and OF25 optics 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 27 * Note: The accuracy of measurement can be outside of the specifications for distances below the defined minimum distance. PI 05M is only available with OF25 optics and PI 08M is only available with OF16 and OF25 optics 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 28: Mechanical Installation

    Mechanical Installation 3 Mechanical Installation 3.1 Dimensions The PI is equipped with two metric M4 thread holes on the bottom side (6 mm depth) and can be installed either directly via these threads or with help of the tripod mount (also on bottom side). The tightening torque of the M4 screws for mounting the PI camera should be between 1 ...
  • Page 29 Figure 5: PI 400i/ PI 450i/ PI 450i G7, dimensions [mm] 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 30 Mechanical Installation Figure 6: PI 640/ PI 640 G7, optics 29°/33° & 53°/60°, dimensions [mm] 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 31 Figure 7: PI 640/ PI 640 G7, optics 13°/15°, dimensions [mm] 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 32 Mechanical Installation Figure 8: PI 640/ PI 640 G7, optics 80°/90°, dimensions [mm] 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 33 Figure 9: PI 640, microscope optics 10°/12°, dimensions [mm] 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 34 Mechanical Installation Figure 10: PI 05M/ PI 08M/ PI 1M, dimensions [mm] 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 35: Changing The Lens

    3.2 Changing the lens The PI camera is offered with several different lenses (lenses depending on the camera variant). To change a lens, rotate it as shown below. For the PI 05M, PI 08M and PI 1M, the protective tube must first be turned off (see Figure 3).

  • Page 36: Fixing The Focus Of The Lens (Only For Pi 05M/ 08M/ 1M)

    Mechanical Installation 3.3 Fixing the focus of the lens (only for PI 05M/ 08M/ 1M) With the PI 05M, PI 08M and PI 1M, it is possible to fix the focus of the lens. To do this, unscrew the protective tube of the camera (see Figure 3). There are three small holes on the lens. Take the three screws that are included and attach them to the three holes.
  • Page 37 Figure 16: Focusing screws for focus ring 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 38: Mounting Accessories (Optional)

    Mechanical Installation 3.4 Mounting accessories (optional) Figure 17: Mounting base, stainless steel, adjustable in 2 axes [Part No.: ACPIMB] Figure 18: Protective housing, stainless steel, Incl. Mounting base [Part No.: ACPIPH] 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 39: High Temperature Accessories

    The CoolingJacket Advanced is available as Standard Version and Extended Version.  The IR camera can be used at ambient temperature up to 50 °C (up to 70 °C with PI 450i/ PI 450i G7). For higher temperatures (up to 315 °C) the CoolingJacket Advanced is provided.
  • Page 40 Mechanical Installation Standard Version Figure 19: CoolingJacket Advanced [Part No.: ACPIxxxCJAS], Standard Version - Dimensions 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 41 Extended Version The Extended Version is provided for applications of the PI series with the PI Netbox and industrial PIF or the USB Server Gigabit and industrial PIF. Both PI Netbox and industrial PIF or USB Server Gigabit and industrial PIF can be integrated in the CoolingJacket. Figure 20: Cooling Jacket Advanced (Extended Figure 21:Cooling Jacket Advanced (Extended Version) Version) with PI Netbox and industrial PIF...
  • Page 42 Mechanical Installation Figure 22: CoolingJacket Advanced [Part No.: ACPIxxxCJAE], Extended Version – Dimensions 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 43: Laminar Air Purge For Coolingjacket

    3.5.2 Laminar air purge for CoolingJacket Laminar air purge for front mounting of the CoolingJacket Advanced (Standard and Extended). Two different versions are available: One for standard camera applications [Part-No.: ACCJAAPLS] and the other for line scanning applications [Part-No.: ACCJAAPLL]. Those two versions are fitting to all focusing units with production date ≥01/2018.

  • Page 44: Outdoor Protective Housing

    Mechanical Installation 3.5.3 Outdoor protective housing  The infrared camera PI and the USB server can also be used for outdoor applications by using the outdoor protective housing.  The outdoor protective housing can be used for any PI camera (lenses up to 90° FOV) ...

  • Page 45: Electrical Installation

    4 Electrical Installation At the back side of the PI there are the two connector plugs. The left plug is for the USB cable. The right connector plug is only used for the process interface. Figure 24: Backside of the camera with connectors Plug for USB cable Plug for PIF cable 1.888.610.7664...

  • Page 46: Process Interface

    Electrical Installation 4.1 Process interface The process interface (electronics within cable as well as industrial interface) must be powered separately (5-24 VDC). Before switching on the power the PIF cable must be connected to the camera. The PI is equipped with a process interface (cable with integrated electronics and terminal block), which can be programmed via the software as an Analog Input (AI) and Digital Input (DI) in order to control the camera or as an Analog Output (AO) in order to control...
  • Page 47 Figure 25: Configuration Standard Process Interface (PIF) The standard process interface provides the following inputs and outputs: Name Description max range / status Analog input 0-10 V Digital input 24 V (active-low = 0…0,6 V) Analog output 0-10 V Alarm output 0/ 10 V Depending on supply voltage;...

  • Page 48: Pin Allocation

    Electrical Installation 4.1.1 PIN allocation 1 VCC 1 INT 2 GND 2 SDA (I²C) 3 SCL (I²C) 4 D - 4 DGND 5 D + 5 3.3 V (Out) Figure 26: Rear side of the camera 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 49 If the process interface of the camera is directly connected to external hardware (without using the supplied PIF cable) an activation of the field „Support proprietary PIF cable” in the menu Tools/ Configuration/ Device (PIF) in the PIX Connect software is necessary. Figure 27: Support proprietary PIF cable Consider that the input of the PIF is not protected if there is a direct PIF connection! A voltage >...

  • Page 50: Industrial Process Interface (Optional)

    Electrical Installation 4.1.2 Industrial Process Interface (optional) For use in industrial environment the industrial process interface with 500 V AC isolation voltage between PI and process is available (connection box with IP65, 5 m, 10 m or 20 m standard or high temperature cable Appendix F –...
  • Page 51 The industrial process interface provides the following inputs and outputs: Name Description max range / status A IN 1 / 2 Analog input 1 and 2 0-10 V D IN 1 Digital input 24 V (active-low = 0…0,6 V) AO1 / 2 / 3 Analog output 1, 2 and 3 0/4-20 mA Alarm output 1, 2 and 3...
  • Page 52 Electrical Installation The process interface has an integrated fail-safe mode. This allows to control conditions like interruption of cables, shut-down of the software etc. and to give out these conditions as an alarm. The time constant of the fail-safe is 1.5 seconds. Controlled conditions on camera and software Standard Process interface Industrial Process interface...

  • Page 53: Example For A Fail-Safe Monitoring Of The Pi With A Plc

    4.2 Example for a Fail-Safe monitoring of the PI with a PLC Figure 29: Fail-Safe monitoring states Fail-Safe monitoring states Breakdown of PIF power supply Malfunction of PI Cable break of fail-safe cable Breakdown of PI power supply/ Interruption of USB cable Interruption of cable PI-PIF Malfunction of PIX Connect software 1.888.610.7664...
  • Page 54 Electrical Installation Figure 30: Fail-Safe monitoring states Fail-Safe monitoring states Breakdown of PIF power supply Malfunction of PI Cable break of fail-safe cable Breakdown of PI power supply/ Interruption of USB cable Short circuit of fail-safe cable Malfunction of PIX Connect software Interruption of cable PI-PIF 1.888.610.7664 www.calcert.com...

  • Page 55: Usb Cable Extension

    4.3 USB cable extension The maximum USB cable length is 20 m. For greater distances between PI and computer or for stand-alone solutions the optional PI NetBox or the USB Server Gigabit is provided: Figure 31: Ethernet direct communication with PI Netbox Figure 32: Ethernet network communication with PI Netbox 1.888.610.7664 www.calcert.com...
  • Page 56 Electrical Installation Figure 33: Stand-Alone operation with PI Netbox Figure 34: USB Server Gigabit 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 57: Irmobile App

    With IRmobile you can monitor and analyze your infrared temperature measurement directly on a connected smartphone or tablet. All you need is an Optris infrared camera. This app runs on most Android (5 or higher) devices with a micro USB port or USB-C port that supports USB OTG (On The Go). The app is easy to use: After you have connected your camera to the micro USB port or USB-C port of your smartphone or tablet, 1.888.610.7664...
  • Page 58  Integrated simulator IRmobile supported for:  Optris IR cameras: PI and Xi series  Optris pyrometers: Compact series, high performance series and video thermometers  For Android 5 (or higher) devices with a micro USB port or USB C port that supports USB OTG (On The Go) 1.888.610.7664...

  • Page 59: Software Pix Connect

    A detailed description is provided in the software manual on the USB stick. See also Help menu in the PIX Connect software (Help → Documentation). Alternatively, the software can also be downloaded via the Optris website under the following link: https://www.optris.global/pix...

  • Page 60: Installation And Initial Start-Up

    Start\Programs\Optris GmbH\PIX Connect 3. To connect the camera to the PC, plug the USB cable to the camera first. Afterwards connect it with the PC (to disconnect the camera and the computer remove the USB cable from the computer first and then disconnect it from the camera).
  • Page 61 Figure 35: Calibration data transfer After the calibration files have been installed the live image from the camera is shown inside a window on your PC screen. 6. Choose the desired language in the menu Tools → Language. 7. Adjust the focus of the image by turning the exterior lens ring at the camera. 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 62: Software Window

    Software PIX Connect 6.2 Software window Figure 36: Software window 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 63 IR image from the camera Temperature profile: Shows the temperatures along max. 2 lines at any size and position in the image. Reference bar: Shows the scaling of temperature within the color palette. Temperature of measure area: Analyses the temperature according to the selected shape, e.g. average temperature of the rectangle.

  • Page 64: Basis Features Of The Software Pix Connect

    Software PIX Connect 6.2.1 Basis features of the software PIX Connect Extensive infrared camera software  No restrictions in licensing  Modern software with intuitive user interface  Remote control of camera via software  Display of multiple camera images in different windows ...
  • Page 65 Video recording and snapshot function  Recording of video sequences and detailed frames for further analysis or documentation  Adjustment of recording frequency to reduce data volume  Display of snapshot history for immediate analysis Extensive online and offline data analysis ...
  • Page 66 Software PIX Connect Automatic process control  Individual setup of alarm levels depending on the process  Definition of visual or acoustic alarms and analog data output  Analog and digital signal input (process parameter)  External communication of software via COM-Ports and DLL ...

  • Page 67: Basics Of Infrared Thermometry

    7 Basics of Infrared Thermometry Depending on the temperature each object emits a certain amount of infrared radiation. A change in the temperature of the object is accompanied by a change in the intensity of the radiation. Searching for new optical material William Herschel by chance found the infrared radiation in 1800. Figure 37: William Herschel (1738-1822) He blackened the peak of a sensitive mercury thermometer.
  • Page 68 Basics of Infrared Thermometry noticed the increasing temperature from violet to red. The temperature rose even more in the area behind the red end of the spectrum. Finally he found the maximum temperature far behind the red area. Nowadays this area is called “infrared wavelength area”. Figure 38: The electromagnetic spectrum and the area used for temperature measurement For the measurement of “thermal radiation”...
  • Page 69 Figure 39: Main principle of non-contact thermometry Infrared thermometers basically consist of the following components:  Lens  Spectral filter  Detector  Electronics (amplifier/ linearization/ signal processing) The specifications of the lens decisively determine the optical path of the infrared thermometer, which is characterized by the ratio Distance to Spot size.
  • Page 70 Basics of Infrared Thermometry The advantages of non-contact thermometry are clear - it supports:  temperature measurements of moving or overheated objects and of objects in hazardous surroundings  very fast response and exposure times  measurement without inter-reaction, no influence on the ...
  • Page 71 Figure 40: Non-contact thermometry 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 72 Basics of Infrared Thermometry Application field: Monitoring of electronic Process control extruding R&D of electronics R&D of electronic parts cabinets plastic parts Process control Process control at R&D of mechanical parts Monitoring of cables manufacturing solar calendering modules 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 73: Emissivity

    8 Emissivity 8.1 Definition The intensity of infrared radiation, which is emitted by each body, depends on the temperature as well as on the radiation features of the surface material of the measuring object. The emissivity (ε – Epsilon) is used as a material constant factor to describe the ability of the body to emit infrared energy.
  • Page 74 Emissivity Figure 42: Spectral emissivity of several materials: 1 Enamel, 2 Plaster, 3 Concrete, 4 Chamotte If the emissivity chosen is too high, the infrared thermometer may display a temperature value which is much lower than the real temperature – assuming the measuring object is warmer than its surroundings. A low emissivity (reflective surfaces) carries the risk of inaccurate measuring results by interfering infrared radiation emitted by background objects (flames, heating systems, chamottes).

  • Page 75: Determination Of Unknown Emissivity

    8.2 Determination of unknown emissivity ► First determine the actual temperature of the measuring object with a thermocouple or contact sensor. Second, measure the temperature with the infrared thermometer and modify the emissivity until the displayed result corresponds to the actual temperature. ►...
  • Page 76 Emissivity ► Cove a part of the surface of the measuring object with a black, flat paint with an emissivity of 0.98. Adjust the emissivity of your infrared thermometer to 0.98 and take the temperature of the colored surface. Afterwards, determine the temperature of a directly adjacent area and modify the emissivity until the measured value corresponds to the temperature of the colored surface.

  • Page 77: Characteristic Emissivity

    8.3 Characteristic emissivity In case none of the methods mentioned above help to determine the emissivity you may use the emissivity table ► Appendix A and Appendix B. These are average values, only. The actual emissivity of a material depends on the following factors: ...

  • Page 78: Appendix A - Table Of Emissivity For Metals

    Appendix A – Table of emissivity for metals Appendix A – Table of emissivity for metals 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 79 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 80: Appendix B - Table Of Emissivity For Non-Metals

    Appendix B – Table of emissivity for non-metals Appendix B – Table of emissivity for non-metals 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 81: Appendix C - Quick Start For Serial Communication

    Appendix C – Quick start for serial communication Introduction One special feature of the PIX Connect software contains the possibility to communicate via a serial COM- Port interface. This can be a physical COM-Port or a virtual COM-Port (VCP). It must be available on the computer where the PIX Connect software is installed.
  • Page 82 Appendix C – Quick start for serial communication 3. Select the baud rate that matches the baud rate of the other communication device. The other interface parameters are 8 data bits, no parity and one stop bit (8N1). These parameters are used in many other communication devices too. The other station must support 8 bit data.

  • Page 83: Appendix D - Interprocess Communication (Ipc)

    The ImagerIPC2.dll will export a bunch of functions that are responsible for initiating the communication, retrieving data and setting some control parameters. The main difference to the former Version 1 (ImagerIPC.dll) is the support of more than one Optris PI via multiple instances of Optris PIX Connect.

  • Page 84: Appendix E - Pix Connect Resource Translator

    Appendix E – PIX Connect Resource Translator Appendix E – PIX Connect Resource Translator A detailed tutorial is provided on the USB stick. PIX Connect is a .Net Application. Therefore it is ready for localization. Localization as a Microsoft idiom means a complete adaption of resources to a given culture. Learn more about the internationalization topics consult Microsoft’s developer documentation on If desired the localization process can be illustrated in detail.

  • Page 85: Appendix F - Wiring Diagrams Pif

    Appendix F – Wiring diagrams PIF Analog Output: The maximum load impedance is 500 Ohm. The analog output can be used as a digital output too. The current value for “no alarm” and “alarm on” is set within the software. 1.888.610.7664 www.calcert.com sales@calcert.com...
  • Page 86 Appendix F – Wiring diagrams PIF Digital Input: Figure 46: Digital input The digital input can be activated with a button to the PI GND-Pin or with a low level CMOS/TTL signal: Low level 0…0.6 V; High level 2…24 V Example Button: Figure 47: Button 1.888.610.7664...
  • Page 87 Analog input (usable voltage range: 0 … 10 V): Figure 48: Analog input Relay output at industrial PIF [Part No.: ACPIPIFMACBxx] The analog output must be set to “Alarm”. The range for AO1-AO3 can be set in the software (no alarm: 0-4 mA/ alarm: 10-20 mA).
  • Page 88 Appendix F – Wiring diagrams PIF Figure 49: Relay output at industrial PIF 1.888.610.7664 www.calcert.com sales@calcert.com...

  • Page 89: Appendix G - Declaration Of Conformity

    Appendix G – Declaration of Conformity 1.888.610.7664 www.calcert.com sales@calcert.com...

This manual is also suitable for:
