1.5 Model overview

The cameras of the PI series are available in the following basic versions:
Model Model code
PI 160 IR
PI 200/ PI 230 BI-SPECTRAL
PI 400i/ PI 450i IR
PI 450i G7 IR
PI 640 IR
PI 640 G7 IR
PI 05M IR
PI 08M IR
PI 1M IR
Table 1: Model overview
Temperature range Spectral range
-20 to 900 °C 7.5 - 13 µm
200 to 1500 °C (optional)
-20 to 900 °C 7.5 - 13 µm
200 to 1500 °C (optional)
-20 to 900 °C 7.5 - 13 µm
200 to 1500 °C (optional)
200 to 1500 °C 7.9 µm
150 to 900 °C
-20 to 900 °C 7.5 - 13 µm
200 to 1500 °C (optional)
200 to 1500 °C 7.9 µm
150 to 900 °C
900 to 2450 °C 500 – 540 nm
575 ...1900 °C 780 – 820 nm
450 to 1800 °C 0.85 - 1.1 µm
Frame rate Typical applications
120 Hz Surface measurements in industrial application
128 Hz Synchronous recording of VIS and IR videos and images
80 Hz Real-time thermographic images in high speed;
Detection of smallest temperature differences (PI 450i)
80 Hz/ 27 Hz Measurement of glass (with Line-Scanning mode)
32 Hz Pin-sharp radiometric recordings in real time
32 Hz Measurement of glass (with Line-Scanning mode)
Up to 1 kHz Measurement of metallic surfaces, graphite or ceramics
with short wavelengths
Bis 1 kHz Measurement of metallic surfaces, graphite or ceramics
with short wavelengths, especially for laser applications
Up to 1 kHz Measurement of metallic surfaces, graphite or ceramics
with short wavelengths
-
