optris PI 160 Operator's Manual

Hide thumbs Also See for PI 160:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
Operator's Manual
®
optris
PI
160/ 200/ 230/ 400/ 450/ 450G7/ 640/ 1M
Infrared camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PI 160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for optris PI 160

Summary of Contents for optris PI 160

  • Page 1 Operator’s Manual ® optris 160/ 200/ 230/ 400/ 450/ 450G7/ 640/ 1M Infrared camera...
  • Page 2 Optris GmbH Ferdinand-Buisson-Str. 14 D – 13127 Berlin Germany Tel.: +49 30 500 197-0 Fax: +49 30 500 197-10 E-mail: info@optris.de Internet: www.optris.de...

  • Page 3: Table Of Contents

    Table of contents Table of contents General Notes ............................. 7 Intended use ..........................7 Warranty ............................9 Scope of delivery .......................... 9 Maintenance ..........................11 1.4.1 Cleaning ..........................11 Model overview ........................... 12 Technical Data ..........................13 General specifications ........................ 13 Electrical specifications .......................
  • Page 4 Mechanical Installation ........................27 Dimensions ..........................27 Mounting accessories (optional) ....................29 High temperature accessories ....................30 3.3.1 Cooling Jacket ........................30 3.3.2 Cooling Jacket Advanced ....................33 Electrical Installation ........................37 Process interface ........................38 4.1.1 PIN allocation ........................40 4.1.2 Industrial Process Interface (optional) ................
  • Page 5 Table of contents Software PIConnect .......................... 49 Installation and initial start-up ..................... 49 Software window ......................... 52 5.2.1 Basis features of the software PIConnect ................54 Basics of Infrared Thermometry ..................... 57 Emissivity ............................63 Definition ............................. 63 Determination of unknown emissivity ..................65 Characteristic emissivity ......................
  • Page 6 Appendix F – Wiring diagrams PIF ......................79 Appendix G – CE Conformity ........................83...

  • Page 7: General Notes

    1 General Notes 1.1 Intended use The optris PI calculates the surface temperature based on the emitted infrared energy of objects [►6 Basics of Infrared Thermometry]. The two-dimensional detector (FPA - focal plain array) allows a measurement of an area and will be shown as thermal image using standardized palettes. The radiometric processing of the picture data enables the user to do a comfortable detailed analysis with the software PI Connect.
  • Page 8 • Avoid abrupt changes of the ambient temperature. • Avoid static electricity, arc welders, and induction heaters. Keep away from very strong EMF (electromagnetic fields). • In case of problems or questions which may arise when you use the infrared camera, please contact our service department.

  • Page 9: Warranty

    General Notes 1.2 Warranty Each single product passes through a quality process. Nevertheless, if failures occur contact the customer service at once. The warranty period covers 24 months starting on the delivery date. After the warranty is expired the manufacturer guarantees additional 6 months warranty for all repaired or substituted product components.
  • Page 10 • Operators manual • Aluminum case • PI450/ 640 only: Hard transport case (IP 67) • PI200/ 230 only: focusing tool for VIS camera Thermal Analysis Kit • PI160 or PI200 • 3 lenses (23°, 6° and 41°, incl. calibration certificate) •...

  • Page 11: Maintenance

    General Notes 1.4 Maintenance Never use cleaning compounds which contain solvents (neither for the lens nor for the housing). 1.4.1 Cleaning Blow off loose particles using clean compressed air. The lens surface can be cleaned with a soft, humid tissue moistened with water or a water based glass cleaner.

  • Page 12: Model Overview

    Modell Model code Measurement range Spectral response Typical applications -20 to 900 °C Exact measurements of metallic and PI 160 7.5-13 µm 200 to 1500 °C (optional) non-metallic surfaces PI 200/ Pi 230 BI-SPEKTRAAL -20 to 900 °C 7.5-13 µm Synchronous recording of VIS and IR 200 to 1500 °C (optional)

  • Page 13: Technical Data

    Technical Data 2 Technical Data 2.1 General specifications Environmental rating: IP67 (NEMA-4) Ambient temperature: 0...50 °C (0...70 °C [PI 450/ PI 450 G7]) Storage temperature: -40...70 °C (-40...85 °C [PI 450/ PI 450 G7]) Relative humidity: 10...95 %, non-condensing Material (housing): Aluminum, anodized Dimensions: PI160/ PI200/ PI230: 45 x 45 x 62 - 65 mm (depending on lens)
  • Page 14 Used standards for vibration and shock: Figure 1: Used standards Stress program (camera in operation): Shock, half sinus 25 g – testing Ea 25 g (acc. IEC 60068-2-27) Acceleration 245 m/s (25 g) Pulse duration 11 ms Number of directions (3 axes with 2 directions each) Duration 600 Shocks...
  • Page 15 Technical Data Shock, half sinus 50 g – testing Ea 50 g (acc. IEC 60068-2-27) Acceleration 490 m/s (50 g) Pulse duration 11 ms Number of directions (3 axes with two directions each) Duration 18 Shocks (3 Shocks each direction) Vibration, sinus shaped –...
  • Page 16 Acceleration 39.3 m/s2 (4.01 g Frequency spectrum 10-106 Hz 0.9610 (m/s (0.010 g /Hz) 106-150 Hz +6 dB/ Octave 150-500 Hz 1.9230 (m/s (0.020 g /Hz) 500-2000 Hz -6 dB/ Octave 2000 Hz 0.1245 (m/s (0.00126 g /Hz) Number of axes Duration (3 x 1 h)

  • Page 17: Electrical Specifications

    Technical Data 2.2 Electrical specifications Power Supply: 5 VDC (powered via USB 2.0 interface) Current draw: Max 500 mA Output Process Interface (PIF 0-10 V (Main area temperature, internal temperature, flag status, alarm) out) [►Appendix F – Wiring diagrams PIF] Input Process Interface (PIF in) 0-10 V (Emissivity, ambient temperature, reference temperature, flag control, triggered recording, triggered snapshots, triggered line-scanner, uncommitted value)

  • Page 18: Measurement Specifications

    2.3 Measurement specifications PI 160 PI 200 PI 230 Temperature ranges 20...100 °C; 0...250 °C; 150...900 °C; Option: 200…1500°C Spectral range 7.5-13 µm Detector UFPA, UFPA, UFPA, 160 x 120 pixel@120 Hz 160 x 120 pixel@128 Hz 160 x 120 pixel@128 Hz...
  • Page 19 Technical Data PI 400 PI 450 PI 450G7 Temperature ranges 20...100 °C; 0...250 °C; -20...100 °C; 0...250 °C; 200…1500°C 150...900 °C; 150...900 °C Option: 200…1500°C Spectral range 7.5-13 µm 7.5-13 µm 7.9 µm Detector UFPA, UFPA, UFPA, 382 x 288 pixel@80 Hz 382 x 288 pixel@80 Hz 382 x 288 pixel@80 Hz (switchable to 27 Hz)
  • Page 20 PI 640 PI 1ML PI 1MH Temperature ranges -20...100 °C; 0...250 °C; 450…1400 °C 700…1800 °C 150...900 °C (500…1400 °C@1kHz) Spectral range 7.5-13 µm 0.92-1.1 µm Detector UFPA, UFPA, UFPA, 640 x 480 pixel@32 Hz 382 x 288 pixel@80 Hz 768 x 480 pixel@32 Hz (switchable to 27 Hz) 382 x 288 pixel@80 Hz...

  • Page 21: Optical Specifications

    Technical Data 2.4 Optical specifications Make sure that the focus of thermal channel and visual channel (PI200/ 230 only) is adjusted correctly. For focusing the thermal camera turn the lens in right direction for “close” and to the left for “infinite” ( ), as well as focusing the visual camera with Figure 2 the focusing tool supplied in the scope of delivery (...
  • Page 22 Figure 3: Focusing tool for VIS camera The variety of different lenses offers the possibility to precisely measure objects in different distances. We offer lenses for close, standard distances and large distances. Different parameters are important if using infrared cameras. They display the connection between the distance of the measured object and the size of the pixel ( Table 2 With the help of BI-SPECTRAL technology at PI200/ 230, a visual image (VIS) can be combined with a...
  • Page 23 Technical Data Table 2: Table with examples showing what spot sizes and pixel sizes will be reached in which distance. For individual configuration there are different lenses available. Wide angle lenses have a radial distortion due to their large opening angle; the software PIConnect has an algorithm which corrects this distortion. * Note: The accuracy of measurement can be outside of the specifications for distances below the defined minimum distance.
  • Page 24 Table 3: Table with examples showing what spot sizes and pixel sizes will be reached in which distance. For individual configuration there are different lenses available. Wide angle lenses have a radial distortion due to their large opening angle; the software PIConnect has an algorithm which corrects this distortion. * Note: The accuracy of measurement can be outside of the specifications for distances below the defined minimum distance.
  • Page 25 Technical Data Figure 4: Measurement field of the infrared camera optris PI representing the 23° x 17° lens...
  • Page 26 ■ HFOV: Horizontal enlargement of the total measuring at object level ■ VFOV: Vertical enlargement of the total measuring at object level ■ IFOV: Size at the single pixel at object level ■ DFOV: Diagonal dimension of the total measuring field at object level ■...

  • Page 27: Mechanical Installation

    Mechanical Installation 3 Mechanical Installation 3.1 Dimensions The PI is equipped with two metric M4 thread holes on the bottom side (6 mm depth) and can be installed either directly via these threads or with help of the tripod mount (also on bottom side). Figure 5: PI160, dimensions [mm] Figure 6: PI200/ 230, dimensions [mm]...
  • Page 28 Figure 7: PI400/ PI450/ PI450G7/ PI640/ PI1M, dimensions [mm]...

  • Page 29: Mounting Accessories (Optional)

    Mechanical Installation 3.2 Mounting accessories (optional) Figure 8: Mounting base, stainless steel, adjustable in 2 axes [Part No.: ACPIMB] Figure 9: Protective housing, stainless steel, Incl. Mounting base [Part No.: ACPIPH]...

  • Page 30: High Temperature Accessories

    3.3 High temperature accessories 3.3.1 Cooling Jacket • The IR camera can be used at ambient temperature up to 50 °C (up to 70 °C with PI450/ PI450G7). For higher temperatures (up to 240 °C) the Cooling Jacket is provided. •...
  • Page 31 Mechanical Installation Figure 10: Cooling Jacket - Dimensions...
  • Page 32 Figure 11: Cooling jacket for PI [Part No.: ACPIxxxCJ] Figure 12: Cooling jacket with mounting bracket...

  • Page 33: Cooling Jacket Advanced

    Mechanical Installation 3.3.2 Cooling Jacket Advanced • The Cooling Jacket Advanced is available as Standard Version and Extended Version. • The IR camera can be used at ambient temperature up to 50 °C (up to 70 °C with PI450/ PI450G7). For higher temperatures (up to 300 °C) the Cooling Jacket Advanced is provided.
  • Page 34 Standard Version Figure 13: Cooling Jacket Advanced [Part No.: ACPIxxxCJAS], Standard Version, 38°/ 62° optics - Dimensions...
  • Page 35 Mechanical Installation Extended Version • The Extended Version is provided for applications of the PI series with the PI Netbox and industrial PIF or the USB Server Gigabit and industrial PIF.
  • Page 36 Figure 14: Cooling Jacket Advanced [Part No.: ACPIxxxCJAE], Extended Version, 38°/ 62° optics - Dimensions...

  • Page 37: Electrical Installation

    Electrical Installation 4 Electrical Installation At the back side of the PI there are the two connector plugs. The left plug is for the USB cable. The right connector plug is only used for the process interface. Figure 15: Backside of the camera with connectors Plug for PIF cable Plug for USB cable...

  • Page 38: Process Interface

    4.1 Process interface The process interface (electronics within cable as well as industrial interface) must be powered separately (5-24 VDC). Before switching on the power the PIF cable must be connected to the camera. The PI is equipped with a process interface (cable with integrated electronics and terminal block), which can be programmed via the software as an Analog Input (AI) and Digital Input (DI) in order to control the camera or as an Analog Output (AO) in order to control the process.
  • Page 39 Electrical Installation Figure 16: Configuration Standard Process Interface (PIF) The standard process interface provides the following inputs and outputs: Name Description max range / status Analog input 0-10 V Digital input 24 V Analog output 0-10 V Alarm output 0/ 10 V Depending on supply voltage;...

  • Page 40: Pin Allocation

    4.1.1 PIN allocation Consider that the input of the PIF is not protected if there is a direct PIF connection! A voltage > 3 V on the INT pin will destroy the device! 1 VCC 1 INT 2 GND 2 SDA (I²C) 3 SCL (I²C) 4 D - 4 DGND...

  • Page 41: Industrial Process Interface (Optional)

    Electrical Installation If the process interface of the camera is directly connected to external hardware (without using the supplied PIF cable) an activation of the field „Support proprietary PIF cable” in the menu Tools/ Configuration/ Device (PIF) in the PIConnect software is necessary. Figure 18: Support proprietary PIF cable We recommend using only a switching contact between INT and DGND as external hardware (button, relay).
  • Page 42 Pin assignment PIF cable (industrial process interface) GREY Interrupt GREEN SCL (I²C) YELLOW SDA (I²C) WHITE 3.3 V BROWN SHIELD Figure 19: Connections of the industrial Process Interface...
  • Page 43 Electrical Installation The industrial process interface provides the following inputs and outputs: Name Description max range / status A IN 1 / 2 Analog input 1 and 2 0-10 V D IN 1 Digital input 24 V AO1 / 2 / 3 Analog output 1, 2 and 3 0-10 V Alarm output 1, 2 and 3...
  • Page 44 The process interface has an integrated fail-safe mode. This allows to control conditions like interruption of cables, shut-down of the software etc. and to give out these conditions as an alarm. Standard Process interface Industrial Process interface Controlled conditions on camera and software ACPIPIF ACPIPIF500V2CBxx Interruption USB cable to camera...

  • Page 45: Example For A Fail-Safe Monitoring Of The Pi With A Plc

    Electrical Installation 4.2 Example for a Fail-Safe monitoring of the PI with a PLC Figure 20: Fail-Safe monitoring states Fail-Safe monitoring states Breakdown of PIF power supply Malfunction of PI Cable break of fail-safe cable Breakdown of PI power supply/ Interruption of USB cable Interruption of cable PI-PIF Malfunction of PIConnect software...
  • Page 46 Figure 21: Fail-Safe monitoring states Fail-Safe monitoring states Breakdown of PIF power supply Malfunction of PI Cable break of fail-safe cable Breakdown of PI power supply/ Interruption of USB cable Short circuit of fail-safe cable Malfunction of PIConnect software Interruption of cable PI-PIF...

  • Page 47: Usb Cable Extension

    Electrical Installation 4.3 USB cable extension The maximum USB cable length is 20 m. For greater distances between PI and computer or for stand- alone solutions the optional PI NetBox or the USB Server Gigabit is provided: Figure 22: Ethernet direct communication with PI Netbox Figure 23: Ethernet network communication with PI Netbox...
  • Page 48 Figure 24: Stand-Alone operation with PI Netbox Figure 25: USB Server Gigabit...

  • Page 49: Software Piconnect

    Software PIConnect 5 Software PIConnect Minimum system requirements: • Windows Vista, Windows 7, Windows 8 • USB interface • Hard disc with at least 30 MByte of free space • At least 128 MByte RAM • CD-ROM drive A detailed description is provided in the software manual on the software CD. 5.1 Installation and initial start-up Uninstall previous versions of the PI Connect before installing the new software.
  • Page 50 1. Insert the installation CD into the according drive on your computer. If the autorun option is activated the installation wizard will start automatically. 2. Otherwise start setup.exe from the CD-ROM. Follow the instructions of the wizard until the installation is finished. The installation wizard places a launch icon on the desktop and in the start menu: Start\Programs\PIConnect To uninstall the software from your system use the uninstall icon in the start menu.
  • Page 51 Software PIConnect Figure 26: Calibration data transfer 4. If necessary adjust the sharpness of the image by turning the exterior lens ring at the camera.

  • Page 52: Software Window

    5.2 Software window Figure 27: Software window...
  • Page 53 Software PIConnect IR image from the camera Icon for quick access to Image subtraction function Icon enabling switching between color palettes Temperature of measure area: Analyses the temperature according to the selected shape, e.g. average temperature of the rectangle. The value is shown inside the IR image and the control displays Alarm settings: Bar showing the defined temperature thresholds for low alarm value (blue arrow) and high alarm value (red arrow).

  • Page 54: Basis Features Of The Software Piconnect

    5.2.1 Basis features of the software PIConnect Extensive infrared camera software • No restrictions in licensing • Modern software with intuitive user interface • Remote control of camera via software • Display of multiple camera images in different windows • Compatible with Windows Vista, 7 and 8 High level of individualization for customer specific display •...
  • Page 55 Software PIConnect Video recording and snapshot function (IR or BI-SPECTRAL) • Recording of video sequences and detailed frames for further analysis or documentation • BI-SPECTRAL video analysis (IR and VIS) in order to highlight critical temperatures • Adjustment of recording frequency to reduce data volume •...
  • Page 56 Automatic process control • Individual setup of alarm levels depending on the process • BI-SPECTRAL process monitoring (IR and VIS) for easy orientation at point of measurement • Definition of visual or acoustic alarms and analog data output • Analog and digital signal input (process parameter) •...

  • Page 57: Basics Of Infrared Thermometry

    Basics of Infrared Thermometry 6 Basics of Infrared Thermometry Depending on the temperature each object emits a certain amount of infrared radiation. A change in the temperature of the object is accompanied by a change in the intensity of the radiation. Searching for new optical material William Herschel by chance found the infrared radiation in 1800.
  • Page 58 He blackened the peak of a sensitive mercury thermometer. This thermometer, a glass prism that led sun rays onto a table made his measuring arrangement. With this, he tested the heating of different colors of the spectrum. Slowly moving the peak of the blackened thermometer through the colors of the spectrum, he noticed the increasing temperature from violet to red.
  • Page 59 Basics of Infrared Thermometry Infrared thermometers are optoelectronic sensors. They calculate the surface temperature on the basis of the emitted infrared radiation from an object. The most important feature of infrared thermometers is that they enable the user to measure objects contactless. Consequently, these products help to measure the temperature of inaccessible or moving objects without difficulties.
  • Page 60 The specifications of the lens decisively determine the optical path of the infrared thermometer, which is characterized by the ratio Distance to Spot size. The spectral filter selects the wavelength range, which is relevant for the temperature measurement. The detector in cooperation with the processing electronics transforms the emitted infrared radiation into electrical signals.
  • Page 61 Basics of Infrared Thermometry Figure 31: Non-contact thermometry...
  • Page 62 Application field: Monitoring of electronic R&D of electronics R&D of electronic parts Process control extruding cabinets plastic parts Process control Process control at R&D of mechanical parts Monitoring of cables manufacturing solar calendering modules...

  • Page 63: Emissivity

    Emissivity 7 Emissivity 7.1 Definition The intensity of infrared radiation, which is emitted by each body, depends on the temperature as well as on the radiation features of the surface material of the measuring object. The emissivity (ε – Epsilon) is used as a material constant factor to describe the ability of the body to emit infrared energy.
  • Page 64 Figure 33: Spectral emissivity of several materials: 1 Enamel, 2 Plaster, 3 Concrete, 4 Chamotte If the emissivity chosen is too high, the infrared thermometer may display a temperature value which is much lower than the real temperature – assuming the measuring object is warmer than its surroundings. A low emissivity (reflective surfaces) carries the risk of inaccurate measuring results by interfering infrared radiation emitted by background objects (flames, heating systems, chamottes).

  • Page 65: Determination Of Unknown Emissivity

    Emissivity 7.2 Determination of unknown emissivity ► First determine the actual temperature of the measuring object with a thermocouple or contact sensor. Second, measure the temperature with the infrared thermometer and modify the emissivity until the displayed result corresponds to the actual temperature. ►...
  • Page 66 1. Set the emissivity to 0.95 and take the temperature of the sticker. 2. Afterwards, determine the temperature of the adjacent area on the measuring object and adjust the emissivity according to the value of the temperature of the sticker. 3.

  • Page 67: Characteristic Emissivity

    Emissivity 7.3 Characteristic emissivity In case none of the methods mentioned above help to determine the emissivity you may use the emissivity table ►Appendix A and Appendix B. These are average values, only. The actual emissivity of a material depends on the following factors: •...

  • Page 69: Appendix A - Table Of Emissivity For Metals

    Emissivity metals Appendix A – Table of emissivity for metals...

  • Page 71: Appendix B - Table Of Emissivity For Non-Metals

    Emissivity non-metals Appendix B – Table of emissivity for non-metals...

  • Page 73: Appendix C - Quick Start For Serial Communication

    Serial communication Appendix C – Quick start for serial communication Introduction One special feature of the PI Connect software contains the possibility to communicate via a serial comport interface. This can be a physical comport or a Virtual Comport (VCP). It must be available on the computer where the PI connect software is installed.
  • Page 74 Command list The command list is provided on the software CD. Every command must expire with CR/LF (0x0D, 0x0A).

  • Page 75: Appendix D - Interprocess Communication (Ipc)

    Interprocess communication (ICP) Appendix D – Interprocess Communication (IPC) The description of the initialization procedure as well as the necessary command list is provided on the CD. The communication to the process imager device is handled by the PI Connect software (Imager.exe) only.

  • Page 77: Appendix E - Pi Connect Resource Translator

    Resource Translator Appendix E – PI Connect Resource Translator A detailed tutorial is provided on the CD. PI Connect is a .Net Application. Therefore it is ready for localization. Localization as a Microsoft idiom means a complete adaption of resources to a given culture. Learn more about the internationalization topics consult Microsoft’s developer documentation on http://msdn.microsoft.com/en-us/goglobal/bb688096.aspx.
  • Page 79 Wiring diagrams PIF Appendix F – Wiring diagrams PIF Analog Output: Figure 37: Analog output For voltage measurements the minimum load impedance must be 10KOhm. The analog output can be used as a digital output too. The voltage for “no alarm” and “alarm on” is set within the software.
  • Page 80 Digital Input: Figure 38: Digital input The digital input can be activated with a button to the PI GND-Pin or with a low level CMOS/TTL signal: Low level 0…0.6 V; High level 2…24 V Example Button: Figure 39: Button...
  • Page 81 Wiring diagrams PIF Analog input (usable voltage range: 0 … 10 V): Figure 40: Analog input Relay output at industrial PIF [Part No.: ACPIPIF500V2CBxx] The analog output must be set to “Alarm”. The voltage level for AO1-AO3 can be set in the software (no alarm: 0 V/ alarm: 2-10 V) REL1-3 (DO1-DO3): = 30 VDC...
  • Page 82 Figure 41: Relay output at industrial PIF...
