Mechanical Installation
Extended Version
The Extended Version is provided for applications of the PI series with the PI Netbox and
industrial PIF or the USB Server Gigabit and industrial PIF. Both PI Netbox and industrial PIF or
USB Server Gigabit and industrial PIF can be integrated in the CoolingJacket.
Figure 26: Cooling Jacket Advanced (Extended
Version) with PI Netbox and industrial PIF
Figure 27:Cooling Jacket Advanced (Extended Version)
with USB-Server and industrial PIF
47-
