Step 4

INSTALLING BATTERY

Hook for battery
(Optional)
1. With door open and deadbolt fully extended, insert lithium battery. Make sure to securely hook
the battery on the provided slot of the interior panel. (Optional) Tighten the screw on the right
side. IMPORTANT: If you're using this battery for the first time, ensure that battery has been fully
charged. Use any standard 5V USB charger to full charge the lithium battery.
pin key
2. After the battery is secured, use the in the accessory bag to HOLD the program button
for 10S. The lock will automatically start self-check (release program button once check starts).
The self-check process determines right or left swinging door and is very important to ensure correct
installation. IMPORTANT: if lock is not properly installed it will open and close repeatedly.
3. Once self-check completes ensure the lock operates smoothly by manually locking and unlocking
the door using the thumb turn on the interior assembly. The deadbolt should operate smoothly
without any interference or binding. If necessary, repeat step 2 and ensure that (a) the deadbolt
was extended and (b) the torque blade was inserted vertically while the deadbolt was extended.
4. Swipe your hand across touchscreen. The lock should close (lock). If the touchscreen is ON,
touch , the lock should lock as well. If deadbolt bounces back or unlocks automatically it
means something is not installed correctly. Go back and repeat step 2, same as above.
11
