Step 3

continued

C1+C2

Insert

and

attached to the cables are secured to prevent the cables from moving.

C1+C2

D1+D2

Tuck

and

lar cable rail on the interior panel.

Hold the cable with your fingers to prevent it from moving

and to prepare mounting onto door.

D1+D2

cables into the grooves on the side. Make sure the foam pads

C1+C2

D1+D2

cables behind the rectangu-

INSTALLING THE INTERIOR ASSEMBLY (G)
