- Page 1 SECURE I SECURE PLUS I SECURE PRO DEADBOLT EDITION INSTALLATION MANUAL...
-
Page 2: Installation Overview
INSTALLATION OVERVIEW Lockly Secure can be fitted for both right swing doors and left swing doors. -
Page 3: Parts List
PARTS LIST 3M Double Sided Tape- EVA Sticker... -
Page 4: Step 1: Preparing Your Door
STEP 1: PREPARING YOUR DOOR 1/2" Drill Hole 12mm 1-3/8"—2" (35mm—50mm) 3-7/8"(98mm) 1" Drill Hole 25mm 2-3/8"(60mm) 2-3/4"(70mm) IMPORTANT NOTICE You are not required to drill a hole in your door. We have provided 3M double sided tape for you to help stabilize the lock during installation. Only drill a hole if you wish to have added stability. - Page 5 STEP 2: ADJUSTING THE BOLT If the latch holes are centered in the drilled hole, no adjustment is needed. If NOT, adjust the latch as shown below. Adjust as shown below (as needed) 2-3/4" 2-3/8" 2-3/4" Push toggle button "A" Pull "C "...
- Page 6 STEP 3: EXTENDING THE BOLT P(2X) When installing the latch, make sure the Extend the latch bolt as shown. position of the "+" mark is on the bottom part of the latch. MAKE SURE THE BOLT IS FULLY EXTENDED (LOCKED) BEFORE INSTALLING PROCEEDING TO THE NEXT STEP...
- Page 7 STEP 4: PREPARING THE EXTERIOR ASSEMBLY Vertical When the bolt is extended, the torque blade should be kept in a vertical position. *REMOVE COUNTERCLOCKWISE (Pole Removed) Install “D” & “C” on “B” in order as shown. *The pole (Labeled X) is used if you drilled a hole in your door. It is not required. If you did not drill a hole in your door, please remove this pole with a flathead screwdriver by turning it counter clock- wise.
- Page 8 STEP 5: INSTALLING THE EXTERIOR ASSEMBLY Note: Please use rotate the torque blade into the vertical position for installation. A. When the bolt is extended, the torque blade should be kept in a vertical position. B. Make sure the cable goes underneath the latch.
- Page 9 STEP 5 (CON’TD): INSTALLING THE EXTERIOR ASSEMBLY I(2X) I(2X) Before screwing check the vertical alignment for the mounting plate and exterior assembly. * H is only required if you drilled a hole in your door. If you did not drill a hole in your door, please do not insert H.
- Page 10 STEP 6: INSTALLING INTERIOR ASSEMBLY Connect the cable. Torque Blade Thumb turn shaft Please insert the RED face of the cable connector into the socket marked in RED. Make sure the connector is securely fixed to the socket. Push the thumb turn shaft into the torque blade. MAKE SURE IT IS IN THE VERTICAL POSITION...
- Page 11 STEP 7: SECURING Lockly SECURE A. Make sure the thumbturn is in a vertical position. Make sure the cover is removed so you can install batteries, but don’t install batteries yet. Warning: Do not install the batteries yet!
-
Page 12: Step 8: Installing Batteries
First install 3 of the 4 batteries. Before installing the last battery, press and hold the PROGRAM button while installing the last battery until you hear a beep from Lockly Lockly will then perform a self check and the keypad screen will start to initiate. This self check will automatically determine and set your door lock to a left open or right open door. -
Page 13: Step 9: Finishing Installation
O(2X) You’re all done! You have completed the Lockly Secure physical lock installation and now you’re ready to get the lock set up. Download the Lockly app from the iOS or Google Play Store to complete your installation. Scan or visit Lockly.com/app... - Page 14 For an online version of this installation guide and videos, visit: http://lockly.com/help...
