Spool Assembly (2, Arm 2); Spool Assembly (3, Boom1); Spool Assembly (4, Bucket) - Daewoo Solar 300LC-V Manual

Spool Assembly (2, Arm 2)

Reference
Number
1
2
3
4

Spool Assembly (3, Boom1)

Reference
Number
1
2
3
4
5
6
7
8
9

Spool Assembly (4, Bucket)

Reference
Number
1
2
3
4
5
6
7
8
9
S0709401K
Page 34
Description
Spool
Spring Seat
Spring
Spool End
Description
Spool
Spring Seat
Spring
Spool End
Plug
Poppet
Spring
O-ring
Backup Ring
Description
Spool
Spring Seat
Spring
Spool End
Plug
Poppet
Spring
O-ring
Backup Ring
Figure 35
Figure 36
Figure 37
Main Control Valve (Kayaba)
