Daewoo Solar 300LC-V Manual page 225

Dimension
A
B
C
D
E 18.0 mm (0.708 in) Radius
F 22.0 mm (0.866 in) Radius
G 30.0 mm (1.181 in) Radius
H 1.0 mm (0.039 in) x 45° Chamfer
Drive Coupling (Main Pump)
Dimensional Details for Figure 4
Measurement
6 ±0.1 mm
(0.2362 ±0.0039 in)
7 ±0.1 mm
(0.2756 ±0.0039 in)
20.0 mm (0.787 in)
7.0 mm (0.275 in)
Models
S300LC-V, S300LL
S340LC-V, S420LC-V, S470LC-V
