Daewoo Solar 300LC-V Manual page 107

9. Install stereo assembly with bolts (2,
Figure 10) after connect speaker wire and
antenna wire.
10. Install right side dash cover (4, Figure 11)
with bolts (1, Figure 10).
11. Install left side dash cover (3, Figure 11)
with bolts (1, Figure 10). Install two
rubbers (2, Figure 11).
12. Install cover (5, Figure 11) on left side
dash cover (3).
NOTE: Connect speaker wire before
installing cover.
13. Connect washer hose located at floor plate
bottom.
14. Install air duct (3, 2 and 1, Figure 12)
located at right side of cab.
NOTE: Connect wire connector of duct
(2, Figure 12).
Cab
Figure 10
2 2
4 4
Figure 11
3 3
1 1
Figure 12
2 2
1 1
ARS1540L
1 1
2 2
3 3
5 5
ARS1530L
2 2
ARS1520L
S0402040K
Page 7
