TIGHTENING TORQUE

Part Name
Hexagon socket head
bolt (Material: SCM
435)
PT filling plug
(Material: S45C)
Wind a seal tape 1 1/2
to 2 turns round the
plug.
PO plug
(Material: S35C)
Main Pump (Kawasaki)
Size Tightening Torque
M 5 70 kg•cm
M 6 120 kg•cm
M 8 300 kg•cm
M 10 580 kg•cm
M 12 1,000 kg•cm
M 14 1,600 kg•cm
M 16 2,400 kg•cm
M 18 3,400 kg•cm
M 20 4,400 kg•cm
PT 1/16 70 kg•cm
PT 1/8 105 kg•cm
PT 1/4 175 kg•cm
PT 3/8 350 kg•cm
PT 1/2 500 kg•cm
PF 1/4 300 kg•cm
PF 1/2 1,000 kg•cm
PF 3/4 1,500 kg•cm
PF 1 1,900 kg•cm
PF 1 1/4 2,700 kg•cm
PF 1 1/2 2,800 kg•cm
Tool Name
B = 4
5
6
7
8
10
12
Allen wrench
14
17
4 Do.
5
6
8
10
6 Do.
10
14
17
17
17
