Panduit PANZONE PZWMC Instructions Manual page 7

P Z Horizontal Slack Manager
AN ONE
Install tray using (4) #12-24 x 1/2 screws provided at desired
RU as shown in figure 3. Refer to recommended layout
section for optimal mounting location(s).
Screw Mounting Locations
Bend Radius Post Installation
Bend radius posts can be installed at any rack location using (1) #12-24 x 2.5" [(1) #12-24 x 1.5" for PZBR3] screw provided as shown in
Figure 1. Post can be customized by removing tabs as show in Figure 2.
Note: Post may be installed over active equipment mounting locations.
Figure 1
#12-24 x 2.5" Screw
For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTRUCTIONS CM315E
Bend
Radius
Post
Page 7 of 11
Figure 3
Figure 2
Score Line
