Recommended Layout (18 RU)
Recommended Layout (26 RU)
For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTRUCTIONS CM315E
Recommended Layout (12 RU)
2 RU of Blanking Panel
2 RU of 24 Port Patch Panels
PZCHSM2
1 RU of Active Equipment
2 RU of 24 Port Patch Panels
PZCHSM2
2 RU of 24 Port Patch Panels
PZCHSM2
2 RU of Active Equipment
2 RU of Blanking Panel
2 RU of 24 Port Patch Panels
PZCHSM2
2 RU of 24 Port Patch Panels
PZCHSM2
2 RU of Active Equipment
2 RU of 24 Port Patch Panels
PZCHSM2
2 RU of 24 Port Patch Panels
PZCHSM2
2 RU of Active Equipment
2 RU of Blanking Panel
Page 10 of 11
24 Port Patch Panel
24 Port Patch Panel
PZCHSM2
24 Port Patch Panel
24 Port Patch Panel
PZCHSM2
Active Equipment
