Cable Routing
Cable must be routed with an adequate slack loop to prevent cable damage. Route cable to point 1 secure to tie down with a T
route cable across the bottom of the enclosure to point 2 secure to tie down with a T
the cables with a T -T at point 3 or 4.
AK Y
Cables Extend
to Patch Panel
For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTRUCTIONS CM315E
Point 2
Page 4 of 11
-T . Route to the desired patch panel after securing
AK Y
Point 4
Point 3
Point 1
-T . Next
AK Y
