Installation

E
QUIPMENT

Table 1: Equipment Packaging

Main Case
Handset
Phone Cord
Power Adaptor
Ethernet Cable
High Phone Stand
Low Phone Stand
Wall Mount Spacers (2)
C
ONNECTING
The connectors of the GXP1200/2010/2020 are located on the bottom of the device while they are located on
the back side of the GXP280/285/2000.

Table 2: GXP Connectors

EXT
PC
LAN
Power Jack
Headset Jack
Handset Jack
GXP-2000 E
GXP–2000 supports two (2) extension units, providing up to 112 additional programmable extensions. Each
GXP Extension unit has 56 multi–purpose keys, dual color LEDs (red/green) and support BLF (Busy Lamp
Field) and Presence.
GXP–2000 Extension package contains:
Grandstream Networks, Inc.
P
ACKAGING
GXP-280/285
Yes
Yes
Yes
Yes
Yes
No
Yes
No
Y P
OUR HONE
Connects the GXP Extension unit directly to the GXP using connection cable.
Draws power from PoE if provided by network.
10/100Mbps RJ-45 ports for PC (downlink) connection.
10/100Mbps RJ-45 port for LAN (uplink) connection. Supports PoE (802.3af).
Draws power from either spare line or signal line.
5V DC power port; UL Certified
RJ22 and 2.5mm for GXP-280/285/2010/2020
RJ22 for GXP-1200
2.5mm for GXP-2000 HW Rev1.0 or later
RJ11
U
XTENSION NIT
GXP-1200 GXP-2000
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes No
No No
Yes No
GXP User Manual
Firmware 1.2.5.3
GXP-2010 GXP-2020
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Page 5 of 44
Last Updated: 03/2011
