Display Language
GXP has up to six line appearances, each with an independent SIP account. Each SIP account requires its
own configuration page. Their configurations are identical.

Table 16: SIP Account Settings

Account Active
Account Name
SIP Server
Outbound Proxy
SIP User ID
Authenticate ID
Grandstream Networks, Inc.
Allows user to choose preferred display language in web UI and key pad UI.
Language file postfix allows the language file to have different postfixes so the
phone can request a particular file. It will append an underscore "_" plus the
string in the language file postfix.
The default language file name is "gxp.lpf". If the field "Language File postfix
"has "NL" string in it, then the phone will request "gxp_NL.lpf" instead of
"gxp.lpf."
User can only load one secondary language.
Supported Secondary language: Czech, Dutch, Estonian, French, German,
Italian, Polish, Portuguese, Slovak, Slovenian and Spanish.
How to set up Secondary Language:
Note: This is similar to updating firmware in your local network environment.
Please refer to http://www.grandstream.com/faqsfirmware.html#4
1. Download the language package
from http://www.grandstream.com/firmware.html
2. Unzip the language package
3. Open the desired language zip file
4. Copy gxp.lpf to the firmware server directory using your local TFTP or HTTP
server.
5. Access the advanced settings of the Web GUI, set "Display Language" to
"Secondary Language"
6. Update and reboot the phone
This field indicates whether the account is active. The default value for the
primary account (Account 1) is Yes. The default value for the other two accounts
is No.
The name associated with each account - displayed on LCD.
SIP Server's IP address or Domain name provided by VoIP service provider.
IP address or Domain name of Outbound Proxy, Media Gateway, or Session
Border Controller. Used for firewall or NAT penetration in different network
environment. If the system detects symmetric NAT, STUN will not work. ONLY
outbound proxy can provide solution for symmetric NAT.
User account information provided by VoIP service provider (ITSP); either an
actual phone number or formatted like one.
SIP service subscriber's Authenticate ID used for authentication. It can be
identical to or different from SIP User ID.
GXP User Manual
Firmware 1.2.5.3
for details.
