NTP server
Public Mode
Distinctive Ring Tone
System Ring Tone
Call Progress Tones
Intercom User ID:
Disable Call Waiting
Disable Call
Waiting Tone
Disable Direct IP Calls
Grandstream Networks, Inc.
This parameter defines the URI or IP address of the NTP (Network Time
Protocol) serve. It is used to display the current date/time.
Default is 'No' (standard mode). Supported only on GXP1200, GXP2010, and
GXP2020. This feature is designed specifically to support the Call Queue
feature implemented on Grandstream's GXE5024 or GXE5028. If set to 'Yes',
this feature will allow other call queue agents to login/logout using their own
login name and password on the same phone. When enabled, all other
accounts will not be active.
Caller ID must be configured. Select a Distinctive Ring Tone 1 through 3 for a
particular Caller ID. The GXP will ONLY use selected ring tones for particular
Caller IDs. For all other calls, the GXP will use System Ring Tone. When
selected and no Caller ID is configured, the selected ring tone will be used for all
incoming calls.
System ring tone. Default is North American standard.
Adjust system ring tone frequencies and cadences based on local telecom
standard.
Using these settings, users can configure ring or tone frequencies based on
parameters from local telecom. By default, they are set to North American
standard.
Frequencies should be configured with known values to avoid uncomfortable
high pitch sounds.
Syntax: f1=val,f2=val[,c=on1/off1[-on2/off2[-on3/off3]]];
(Frequencies are in Hz and cadence on and off are in 10ms)
ON is the period of ringing ("On time" in 'ms') while OFF is the period of silence.
In order to set a continuous ring, OFF should be zero. Otherwise it will ring ON
ms and a pause of OFF ms and then repeat the pattern. Up to three cadences
are supported.
This field is used to configure the Intercom key in the phone. For GXP2010 and
GXP2020 only
If the phone is working with a GS GXE502X IP-PBX it can be configured in the
following manner:
To page an extension : [intercom feature code]+[*]+[extension number]
x
To page a group : [paging group feature code]+[*]+[group extension]
x
Default is No. If set to Yes, the call waiting feature will be disabled.
Default is No. If set to Yes, the call waiting tone will be disabled.
Default is No. If set to Yes, direct IP calls will be disabled
