Grandstream Networks GXP2000EXT Manual page 36

http://arttel.ru
Use Quick IP Call Mode
Disable Conference
Lock keypad update
Enable MPK Sending
DTMF
Disable DND
Disable Transfer
Disable Multicast Filter
Semi-Attended Transfer
Mode
Disable Headset Button Default is No. If set to Yes, Headset button will be disabled and pressing it will
Enable Constraint Mode Default is No. If set to Yes, the phone will limit the end-user's access to the
Display CID instead of
Name
Headset Port Type
Headset TX gain (dB)
Headset RX gain (dB)
Grandstream Networks, Inc.
Dial an IP address under the same LAN/VPN segment by entering the last octet
in the IP address.
In the Advanced Settings page there is an option "Use Quick IP-call mode".
Default setting is No. When set to YES, and #XXX is dialed, where X is 0-9 and
XXX <=255, phone will make direct IP call to aaa.bbb.ccc.XXX where
aaa.bbb.ccc comes from the local IP address REGARDLESS of subnet mask.
#XX or #X are also valid so leading 0 is not required (but OK). See Quick IP
Call Mode for details.
Default is No. If set to Yes, conference will be disabled.
If set to "Yes", the configuration changes via keypad are disabled.
Default is No. If set to "Yes", Muti-Purpose keys can be sent as DTMF.
For GXP2020/2010/2000.
Default is No. If set to "Yes", the "DND" button on keypad will be disabled. For
GXP2000, MUTE/DEL button functions as DND button when pressed while
phone is idle.
Default is No. If set to Yes, transfer will be disabled.
Default is No. If set to Yes, the phone will not filter out (discard) multicast
packets.
Default is RFC5589 mode, which allows the REFER message to be sent after
INVITE is answered so that the TRANSFER is not finished until it receives
responses
(e.g. 4xx, 2xx) from the SIP server.
have no effect.
configuration of the phone.
If set to "Yes", CID will be displayed in the screen instead of Name. Default is
"No". For GXP280/285 only.
Select either 2.5mm or RJ22 headset ports to be adjusted.
Increases the selected headset's (2.5mm or RJ22) TX gain by + or – 6dB.
Default is 0dB
Increases the selected headset's (2.5mm or RJ22) RX gain by + or – 6dB.
Default is 0dB
GXP User Manual
Firmware 1.2.5.3
Page 36 of 44
Last Updated: 03/2011
