2.2 Required Equipment
The following equipment and documents are included in the EVM evaluation kit:
• Evaluation board (EVM)
• Mini-USB cable
• Power cable
The following equipment is not included in the EVM evaluation kit, but is required for evaluation of this product:
• TSW14J57EVM data capture board and related items
• High-Speed Data Converter Pro software.
• PC computer running Microsoft
• Two low-noise signal generator one for DEVCLK (Sampling clock) second for providing reference signal. TI
recommends the following generators:
– Rohde & Schwarz ®
– Rohde & Schwarz ®
• One low-noise signal generator for analog input. TI recommends the following generators:
– Rohde & Schwarz ®
– Rohde & Schwarz ®
• Bandpass filter for analog input signal (2897 MHz or desired frequency). The following filters are
recommended:
– Bandpass filter, greater than or equal to 60-dB harmonic attenuation, less than or equal to 5% bandwidth,
greater than 18-dBm power, less than 5-dB insertion loss
™
– Trilithic 5VH-series tunable BPF
™
– K&L Microwave BT-series tunable BPF
– TTE KC6 or KC7-series fixed BPF
• Signal-path cables, SMA or BNC (or both SMA and BNC)
By default, the ADCxxDJxx00RFEVM has an external clocking solution. A few small board modifications enable
onboard clocking. If onboard clocking is used, the following equipment is recommended.
• One low-noise signal generators. TI recommends similar models to the analog input source.
• A bandpass filter for the analog input. TI recommends a filter similar to the analog-input path filter.
The frequency of clock source used to drive the external reference clock (labeled REF CLK J17)
displayed on the first page of the GUI under Reference Clock. The reference clock frequency is
calculated by the GUI using JMODE and the sampling frequency (Fs) entered by the user. The
reference clock generator and device clock generator must be frequency-locked using a common
10-MHz reference.
SLAU640A – APRIL 2019 – REVISED JUNE 2021
Submit Document Feedback
® Windows ® 7, or 10
SMA100B
SMA100A
SMA100B
SMA100A
Copyright © 2021 Texas Instruments Incorporated
Note
Equipment
ADCxxDJxx00RF Evaluation Module 5
