Status
Status light: to show the battery module's status (
RS232 Terminal
Console Communication Terminal: (RJ45 port) follow RS232 protocol, for manufacturer or
professional engineer to debug or service.
Link Port 0, 1
Link Port 0, 1 Communication Terminal: (RJ45 port), CAN communication , between multiple
serial battery modules and control module.
Power Terminals
The power cable terminal is O-ring type (M8 screw).
The terminal has a plastic cover which need to be add on after finish the wiring connection.
Dismantle of the cover must use attached special tool. Insert the tool into the 4 holes of the
cover.
●
,
