v. Click OK to Confirm Trim Operation.
IMPORTANT: Trimmed data cannot be recovered.
7.7.2
Using the Quality Map tool
The Quality Map tool allows the user to assess in real-time if enough data is
collected in the area of the scan.
i. Click on the Disable Captured Color icon.
The 3D scan will display in
ii. Click on the Quality Map icon.
Regions where sufficient data has been scanned are
displayed in green, regions where insufficient data has been
scanned are displayed in red.
iii. Rescan the areas displayed in
red that are required for the
planned restoration work.
TIP: Do not over-scan in an effort
to recover extra data:
it is better to reset and redo the
scan if the result is not satisfactory.
iv. Click on
tool.
The Color Map is disabled automatically when you select another Scan Tool or
move to the next step in the scan workflow.
the Enable Captured Color icon, to disable the Color Map
grayscale.
