7.1.2
Using the Scan Tip
Each scanner is delivered with three (3) reusable tips, that can be sterilized in an
autoclave up to 250 times.
1. Attach the tip with the mirror side facing down-
ward. Firmly press the tip onto the scanner until you
hear it lock into place.
2. Detach the tip by pressing the button located on
the bottom of the handpiece (1) while pulling away
from the scanner (2).
IMPORTANT: To avoid scanning errors, make sure the scanner tip clicks
securely into place
3. Rotate.
To make the scanning process more comfortable for
maxillary scans, you may remove the tip by pressing the
button (1) located on the bottom of the handpiece and
rotate the scanner tip 180 degrees (2).
For ease of use, hold the EzScan handpiece as
shown.
4. Start.
To begin scanning, press the Start/Stop button
on the top of the scanner, or click the
Start/Stop icon in the right-hand Scanning
Tools menu.
IMPORTANT: Make sure the computer on which the EzScan-i
software is installed is connected to an external power source
before starting to scan with the EzScan.
Do not scan using a battery-powered computer.
