7.6 2D Image Capture
During the scan process, press the "C" key on your keyboard to take and store 2D
images automatically. 2D images are displayed in thumbnail format in the
bottom left-hand corner of the screen.
Click on a thumbnail image to view the
selected photo in more detail.
• Delete unwanted images by
selecting them and clicking on the
delete icon as shown.
In the final Order Preview page, you
can consult 2D images taken during the
scan by clicking on the 2D IMAGES button
7.7

Using Scan Tools

At each step of the scan workflow, you can use the features available in the right-
hand Scan Tools menu.
7.7.1
Using the Scan Trim tool
After scanning, you can use the Trim tool in the right-hand Scan Tool menu
to trim the 3D model and remove any unwanted data.
To use the Trim tool:
Click on the Scan Trim icon in the Scan Tool menu.
i.
ii. Select the Scan Trim size.
iii. Click+Hold [Ctrl] to select the surface area to be removed,
iv. Click on the Delete icon to remove unwanted scan areas.
