7.8.3

Auto-Realignment

The Auto-Realignment feature enables you to optimize the scans of the
maxillary and mandibular arches. The EzScan-i software's AI will recalculate the
results using specially developed imaging algorithms, retaining only the most
accurate frames for 3D image reconstruction.
1.
Realignment icon. You will be prompted to
confirm the optimization.
2.
optimization of the scans.
NOTE: Auto-Realignment may take a couple of minutes.
7.8.4

Using Bite Alignment Tools

When you have successfully completed the Bite Alignment for your patient, you can
use the Bite-Alignment tools to visually inspect the quality of the alignment scans.
The Bite-Alignment Tool menu is displayed below the 3D
reconstructed image of the bite alignment.
Occlusion Distance Map
To visually check the clearance distance
between the maxillary and mandibular arch
scans:
i. Click on the Occlusion Distance Map icon in
the Bite Alignment Tool menu.
ii. Adjust the color map by dragging the visual slider to the
desired value.
Contact points are indicated as shown.
Open Jaws
You can use this tool to open the jaws after
the bite alignment, to better inspect your
scans.
Swap Jaws
Allows the user to swap jaw scans (in case
lower was scanned instead of upper or
vice versa).
In the Tools menu, click on the Auto-
Click OK to start Auto-Realignment
Page 55
