2. Scan a 2-3 teeth and 7-8mm gum segment
on the LEFT molar/pre-molar region in
Occlusion.
You will be prompted to select a
mandibular paired point on the bite scan
segment.
3. Click Select Point and choose a point on the
mandibular arch of the LEFT-side bite scan.
4. When you have positioned the marker, HOLD [Ctrl]
and click: a yellow dot will indicate the selected
mandibular-paired point.
5. Click Confirm Point.
The bite scan segment and the selected
mandibular-paired point is displayed automatically
in the top right-hand of the screen.
6.
You will be prompted to select the corresponding paired point on the
mandibular arch.
7. As before, click Select Point, HOLD
[Ctrl] and click: a yellow dot will
indicate the selected mandibular-
paired point.
8. Click Confirm Point.
You will be prompted to select a maxillary-paired point on the bite scan.
When selecting pair points, choose an easily identifiable surface, without
dense image complexity.
The EzScan-i software calculates the matching position based on recognizable
surrounding surfaces and not on the specific point you have chosen, so you
do not need to worry about replicating the exact position.
