Table 2-14. ELVIS Voltage Selection Jumper (JP6)
JP6 Setting
OFF
ON

The external power supply must be disconnected from the board
when
JP6
age to the EZ-KIT Lite board and ELVIS unit.

ELVIS Select Jumper (JP8)

The ELVIS select jumper (
to an ELVIS station (see
installed, the connections to the push buttons and LED are redirected to
the ELVIS station, instead of the processor. The jumper setting is shown
in Table 2-15.
Table 2-15. ELVIS Select Jumper (JP8)
JP8 Setting
OFF
ON
ADSP-BF537 EZ-KIT Lite Evaluation System Manual
ADSP-BF537 EZ-KIT Lite Hardware Reference
Mode
Powered from an external power supply (default)
Powered from an ELVIS station
is installed. In this case, the power supply can cause dam-
) configures the EZ-KIT Lite's connection
JP8
"ELVIS Interface" on page
Mode
Not connected to an ELVIS station (default)
Connected to an ELVIS station
1-17). When is
JP8
2-17
