EUROCOM M620NC Service Manual page 15

Feature
Keyboard & Winkey Keyboard
Pointing Device
PCMCIA One Type-II PCMCIA (3.3V/5V) CardBus PC Card Slot
Card Reader Embedded 4-in-1 Card Reader (MS/ MS PRO/ SD/ MMC)
Interface Three USB 2.0 Ports (1.1 Compatible)
One External Monitor Port
One Headphone-Out Jack
One Microphone-In Jack
Communication AZALIA 56K Fax Modem - V.90 & V.92 Compliant
10/100M Fast Ethernet LAN
Intel PRO/Wireless 3945ABG PCIe Interface Wireless LAN Module (Option)
USB (2.0) Bluetooth Module (Option)
Power Management Supports ACPI 2.0 and APM v 1.2
Power Full Range AC/DC Adapter - AC Input 100 ~ 240V, 50 ~ 60Hz / DC Output 18.5V, 3.5A
4 Cell Smart Lithium-Ion Battery Pack, 5200mAH, 38.48W
10 Cell Smart Lithium-Ion Battery Pack, 13000mAH, 96.2W
Environmental Spec Temperature
Operating:
Non-Operating:
Dimensions & 281mm (w) * 237mm (h) * 32 - 35mm (d)
Weight
Optional Optical Device Module Options:
Dummy ODD
DVD-ROM Drive Module
DVD/CD-RW Combo Drive Module
DVD Dual - Supporting Super MULTI Drive Module
USB (2.0) Bluetooth Module (Including Bluetooth Cable)
All manuals and user guides at all-guides.com
Specification
Built-In TouchPad
One RJ-11 Modem Jack
One RJ-45 LAN Jack
One DC-in Jack
One Mini-IEEE 1394 Port
Supports Wake On Modem Ring
Supports Wake On LAN
Relative Humidity
° °
5 C ~ 35 C
° °
-20 C ~ 60 C
1.2kg (with 1.8" 30GB HDD, DVD Dual & 4 Cell Battery
Intel PRO/Wireless 3945ABG PCIe Interface Wireless
LAN Module (Option)
10 Cell Smart Lithium-Ion Battery Pack, 13000mAH,
96.2W
Operating: 20% ~ 80%
Non-Operating: 10% ~ 90%
Introduction
System Specifications 1 - 3
