RJ45 Define
Video Link (TIA/EIA-568-B)
1. Orange-white
2. Orange DATA0 -
3. Green-white
4. Blue
5. Blue-white
6. Green
7. Brown-white
8. Brown
Caution
This device not support MST (Multi Stream Transport) hub function based on DP1.2
Trouble Shooting
1. The wiring must away from any equipment with electromagnetic wave, i.e.: mobile phone, microwave,
radio equipment, fluorescent lamp, high voltage power lines.
2. The cable must pull in straight to avoid any crosstalk interference and the transmission stability.
3. This device HDBaseT port is not general Ethernet signal; do not connect with Network devices to avoid
damage.
4. The receiver unit working temperature is higher which is in normal condition.
5. The bottom dip switch was no function which is reserve.
Package Include
DP02ET DVI Transmitter x 1 pcs
DP02ER DVI Receiver x 1 pcs
Mounting Screw pack x 1 bags
Power Adapter x 2 pcs
DATA0 +
DATA1 +
DATA2 +
DATA2 -
DATA1 -
DATA3 +
DATA3 -
User Manual
