The control board also provides SCSI-2 data and power to peripherals.
Backup device tray
Reset switch
Service port
SCSI disk drive tray
Figure 1-6
1.3.4 System Board
The SPARCserver 1000 system must have at least one system board installed in
card cage slot 0. The system board (Figure 1-6) features:
•
One single-ended narrow SCSI-2 port
•
10Base-T Ethernet port
•
Two serial ports
•
One or two SuperSPARC modules
Preparing for Installation
SCSI Tray Assembly
Control board
1
1-9
